TPMS403
DIY TYRE PRESSURE MONITORING SYSTEM
EXTERNAL (CAP TYPE) 4 SENSOR
MONITOR
- Reliable & Easy to Fit DIY Installation
- 12 Volt DC Cig Lead Power Socket
- Can Connect up to 4 Sensors
- Widescreen LCD Display: 35mm Diagonal
(30W x 15H mm)
- Adjustable Display Angle: >90°
- Pressure Parameter Setup
- Low Pressure / Temperature Alarm
- Settings & Menu Buttons
- Sensor Learning
- Sensor Position
- Sensor Battery Alert
- PSI or Bar Select
- Operating Frequency: 433.92 MHZ
- Operating Temperature -40°c to 85°c
INSTRUCTION MANUAL
SENSORS
- External Mounting
- 23mm Sensor Caps
- Water Resistant
- Screws onto Valve Stem for quick & easy installation
- Tyre Pressure Range: 0 to 50 PSI
- Pressure Accuracy 1.45 PSI
- Transmission Frequency: 433.92 MHZ
- Working Temperature -20c to 70c
- Operating Voltage: 3.0V (3.0 - 3.6V)
- Security: Hex Locking Nuts & Tamper Basket
- Replaceable CR1632 Button Battery
INCLUDED
- Installation
Accessories
