Ctrl Command get_serial_number
Function
returns the individual serial number of the RTC
®
Result
RTC
4 serial number as an unsigned 16-bit value
Integration
Pascal:
C:
Basic:
Comments
• The command is helpful when using several RTC
See
chapter 5.4, page
Ctrl Command get_startstop_info
Function
provides information about internal and external list starts and stops, as well as
information about the laser signals
Result
Status signal word (unsigned 16-bit value):
Bit #0 (LSB)
Bit #1
Bit #2
Bit #3
Bit #4
Bit #9
Bit #10
Bit #12
The remaining bits are reserved.
Integration
Pascal:
C:
Basic:
Comments
• The status bits #0 ... #3 are reset after the command is executed.
References
get_counts,
®
RTC
4 PC Interface Board
Rev. 1.3 e
10 Commands And Functions
function get_serial_number: word;
unsigned short get_serial_number(void);
function get_serial_number()%
43.
= 1:
An internal START has been executed since the last
= 1:
An external START has been executed since the last
= 1:
An internal STOP (command stop_execution) has been executed since the last
get_startstop_info
command was called.
= 1:
An external STOP has been executed since the last
logical AND operation of the signals /STOP and /STOP2:
= 1:
The external /STOP input (and the /STOP2 input of the MARKING ON THE FLY connector) are
currently set to HIGH or not connected.
= 0:
The external /STOP input (or the /STOP2 input of the MARKING ON THE FLY connector) are
currently set to LOW.
Enable Laser Status. Bit = 1: Laser is enabled. See
TTL Laser Signal Status. Bit = 1: Laser signals are active-low (Jumper X10 is open; see
logical AND operation of the signals /START and /START2:
= 1:
The external /START input (and the /START2 input of the MARKING ON THE FLY connector)
are currently set to HIGH or not connected.
= 0:
The external /START input (or the /START2 input of the MARKING ON THE FLY connector) are
currently set to LOW.
function get_startstop_info: word;
unsigned short get_startstop_info(void);
function get_startstop_info()%
get_status
®
4 board
®
4 boards in one computer.
get_startstop_info
command was called.
get_startstop_info
command was called.
get_startstop_info
command was called.
enable_laser
and disable_laser.
page
59).
85
