6.3 Primary Scan Head Connector

The 25-pin D-SUB connector for the scan head is
compatible with most scan heads which use the
XY2-100 standard. The pin out is shown in
on page 54.
DO NOT CONNECT (25)
GND (24)
GND (23)
DO NOT CONNECT (22)
* STATUS1+ (21)
DO NOT CONNECT (20)
STATUS+ (19)
(optional) CHAN3+ (18)
CHAN2+ (17)
CHAN1+ (16)
SYNC+ (15)
CLOCK+ (14)
Pin out of the 25-pin female D-SUB connector for the scan head
(VB2)
* The STATUS1± channel can only be used together with
®
intelliSCAN scan systems, else: "DO NOT CONNECT"

Control Signals

Data channels CHAN1 through CHAN3 transmit
control values to the scan head. The SYNC and CLOCK
channels transmit synchronization and clock signals
to the scan system.
The CHAN3 channel is optionally provided for
controlling a third axis in a 3-axis system.
Please contact SCANLAB for further information (also
see chapter 7 "Options", page
For additional information, please contact SCANLAB.

Status Signals

The STATUS channel receives XY2-100 standard
compliant status signals returned by the scan system.
Consult your scan system's operating manual to
determine which status signals are generated by your
scan system and how they can be applied for moni-
toring purposes.
®
RTC 4 PC Interface Board
Rev. 1.3 e
6 Electrical Connections
6.4 Secondary Scan Head
The 26-pin connector "2. SCANHEAD" on the RTC
figure 25
board is designed for connecting a second scan head
in a double scan head configuration. The pin out of
this connector is shown in
The signals on this connector are optional and must
be enabled by SCANLAB. Please contact SCANLAB for
further information. Also see
page
(13) DO NOT CONNECT
SCANLAB recommends using an additional slot cover
(12) DO NOT CONNECT
(11) GND
for connecting the second scan head. A suitable slot
(10) DO NOT CONNECT
cover with a 25-pin D-SUB connector – with a pin out
(9) DO NOT CONNECT
(8) STATUS1 – *
as shown in
(7) DO NOT CONNECT
SCANLAB.
(6) STATUS –
(5) CHAN3 – (optional)
(4) CHAN2 –
(3) CHAN1 –
(2) SYNC –
(1) CLOCK –
25
57).
Pin out of the on-board "2. SCANHEAD" connector
* The STATUS1± channel can only be used together with
intelliSCAN
Connector (Optional)
figure 26 on page
57.
figure 25 on page 54
CLOCK – (1)
SYNC – (3)
CHAN1 – (5)
CHAN2 – (7)
CHAN3 – (9)
STATUS – (11)
DO NOT CONNECT(13)
* STATUS1 – (15)
DO NOT CONNECT(17)
DO NOT CONNECT(19)
GND (21)
DO NOT CONNECT(23)
DO NOT CONNECT(25)
®
scan systems, else: "DO NOT CONNECT"
®
4
54.
chapter 7 "Options",
– is available from
(2) CLOCK+
(4) SYNC+
(6) CHAN1+
(8) CHAN2+
(10) CHAN3+
(12) STATUS+
(14) DO NOT CONNECT
(16) STATUS1+ *
(18) DO NOT CONNECT
(20) GND
(22) GND
(24) DO NOT CONNECT
(26) DO NOT CONNECT
26
54
