Scanlab RTC 4 Installation And Operation Manual page 79

Ctrl Command control_command
Integration Pascal:
C:
Basic:
Comments • The control_command
scan systems. Conventional scan systems will ignore the command.
• Data sources selected via the
another source is selected.
• Data returned to the RTC
and get_waveform. Switching to a different data source causes a short (serial trans-
mission-related) delay before transmission of the first data. Therefore, wait at least
50 µs before reading the data.
• Five seconds after every new start or reset or after sending the command code 0500
via the
signal) will be returned on all receiving channels. The statusword can be queried via the
get_head_status
• During a temporary error state after the maximum allowed temperatue was exceeded
(flag bit#7 = 0), the scan head's output stages of the affected axis are at least tempo-
rarily deactivated. The intelliSCAN
temperatur drops again below the maximum allowed temperature.
• During a "permanent error state" after a critical error, all output stages will remain
deactivated. Critical errors include improper internal or external voltages and reaching
critical edge positions.
• If a critical error occurs, the intelliSCAN
in which the output stages of the affected axis remain deactivated – even if the critical
error was only temporarily present. Normal operation is not resumed. Flag bit#9 = 0 is
only reset via a hardware reset. Critical errors are for instance improper internal voltages
(flag bit#13 = 0), external power supply interruption (flag bit#8 = 0) or reaching a crit-
ical edge position (flag bit#5 = 0).
• During both temporary and permanent error states, the intelliSCAN
transmit data to the control board. Even in these states, switching or selection of data
signals for diagnostic purposes is still possible.
• The flags indicate the scan system's operational state. The scan module can return one
of two flag blocks indicating the current operational state (code = 0528
alternatively one of two further flag blocks indicating the operational state at the
moment of the most recently occured operation interruption. After every successful
restart – and, as long as no error has occured – all status informations of the two latter
blocks are irrelevant. Only, as soon as an error causes a switch into a temporary or
permanent error state, the current status values will be saved into these two blocks. In
this case, also an event code is simultaneously set, indicating which particular event
caused the error state. This event code can be read out separately (code = 052A
• To convert angle bit-values (actual position, set position, position error) or bit/ms values
(actual speed) returned to the RTC
to be multiplied by the scan system's calibration factor. The calibration factor (in
mrad/bit) can be read out via code = 0523
• Exact values for the internal voltages referred to in the table can vary for different
versions of the intelliSCAN
References get_value, get_head_status, set_trigger,
®
RTC 4 PC Interface Board
Rev. 1.3 e
10 Commands And Functions
procedure control_command(head, axis, data: word);
void control_command(unsigned short head, unsigned short axis, unsigned short data);
sub control_command(ByVal head As Integer, ByVal axis As Integer, ByVal data
As Integer)
command can only be used in conjunction with intelliSCAN
control_command
®
4 can be queried via the commands get_value, set_trigger,
control_command command, the statusword (XY2-100-compliant status
command, too.
®
®
.
command will be transmitted until
will return to normal operation as soon as the
®
automatically enters a permanent error state,
®
4 into mrad or mrad/ms, the returned values have
.
H
get_waveform
®
H
®
continues to
, 0529 ) or
H H
).
H
79
