2.3 Board Dimensions And Layout

VB2
VB3
X6 X7 X3
Legend
VB2 . . . . . . . . . . . . . . . . . . Primary scan head connector (D-SUB 25-pin female)
VB3 . . . . . . . . . . . . . . . . . . Laser connector and analog output ports (D-SUB 9-pin female)
MARKING ON THE FLY . . . . Connector for Processing-on-the-fly applications (optional) –
2. SCANHEAD . . . . . . . . . . Secondary scan head connector (optional)
EXTENSION 1. . . . . . . . . . . Connector with a 16-bit digital input and a 16-bit digital output
EXTENSION 2. . . . . . . . . . . Connectors for the RTC
LASER EXTENSION . . . . . . . Additional laser connector with 8-bit digital output port
X6/X7/X3 . . . . . . . . . . . . . Jumper bank for laser connector VB3
X10 . . . . . . . . . . . . . . . . . . Jumper for setting the laser signal level
X8/X9 . . . . . . . . . . . . . . . . Jumper bank for the LASER EXTENSION connector
SN . . . . . . . . . . . . . . . . . . . Serial number
All connectors are described in
The jumper settings are described in detail in
®
Layout of the RTC 4 standard version
®
RTC 4 PC Interface Board
Rev. 1.3 e
2 Product Overview
160 mm
MARKING ON THE FLY
2. SCANHEAD
PCI CONNECTOR
please refer to the supplement manual
(optional: connector for the RTC
®
please refer to the supplement manual
section 6 on page 52.
section 8.1 on page
EXTENSION 1
X10
"Processing-On-The-Fly Software"
®
4 I/O Extension Board)
4 I/O Extension Board (optional) –
"I/O Extension Board"
58.
EXTENSION 2
LASER EXTENSION
X8 X9
SN
1
8
