LaserOn
Delay
Mark
Command
Legend
1 Variable polygon delay, shorter than the specified edgelevel.
2 Variable polygon delay, longer than the edgelevel.
The laser is turned off between the two mark or arc commands.
3 Mark delay.
Laser control timing during a polyline with variable polygon delays.
An edgelevel was defined with the command set_delay_mode.
®
RTC 4 PC Interface Board
Rev. 1.3 e
4 Principle Of Operation
LaserOff
Delay
Mark
1 2
Command
LaserOn LaserOff
Delay Delay
Last Mark
Command 3
In This Polyline
Time
10
