Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553, NZS 5262 and
have been certifi ed by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
P33 Gas Log Fireplace
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration,
service or maintenance can cause injury or
property damage. Refer to this manual. For
assistance or additional information consult
an authorised installer, service agency or the
gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
fl ammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-537a
Models:
P33NG3-R
P33LPG3-R
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any
appliance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas
supplier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
02/04/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency P33NG3-R
Summary of Contents for Regency P33NG3-R
- Page 1 Owners & Installation P33 Gas Log Fireplace Models: P33NG3-R P33LPG3-R PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, alteration, What to do if you smell gas: service or maintenance can cause injury or Do not try to light any property damage.
-
Page 2: To The New Owner
As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency ®... -
Page 3: Table Of Contents
Glass Gasket ...............41 Flueing Introduction ............9 Door Glass..............41 Exterior Flue Termination Locations ......10 Fan Replacement ............41 ® Regency Direct Flue System (Flex) ......11 Removing Valve ............42 Horizontal Terminations Only ....... 11 Installing Valve .............42 Installation Procedures ........12 Simpson Dura-Vent Flueing.........13 PARTS LIST Simpson Dura-Vent Flueing Components List.....14... -
Page 4: Data Badge
DATA BADGE DATA BADGE NOTE: Regency ® units are constantly being improved. This is a copy of the label that accompanies each P33 Gas Fireplace. We have printed a copy of the contents here for your review. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Installation
YOUNG CHILDREN SHOULD BE prior to operating this appliance. CAREFULLY SUPERVISED WHEN THEY ARE IN THE SAME ROOM AS THE APPLIANCE. CLOTHING OR OTHER FLAMMABLE MATERIAL SHOULD NOT BE PLACED ON OR NEAR THE APPLIANCE. ® Regency P33 Gas Log Fireplace... -
Page 6: Installation Checklist
This includes the internal fl ooring, the appliance must be installed on a blower option as well. metal or wood panel extending the full width and depth of the appliance. ® Regency P33 Gas Log Fireplace... -
Page 7: Clearances Combustible Mantels
Combustible mantel leg clearances as per diagram below: Maximum 1-1/2" (38mm) projection at 2" (51mm) minimum clearance. Clearances for Bay or Flush Front The HeatWave Duct Kit has different clearance and framing requirements, check the HeatWave manual for details. ® Regency P33 Gas Log Fireplace... -
Page 8: Framing And Finishing
fl ue to combustible materials for fl ex for Simpson Dura-Vent, see page 7. 6) Use steel studs for framing where the 1-1/2" (38mm) clearance from the fl ue to combustible material cannot be maintained. ® Regency P33 Gas Log Fireplace... -
Page 9: Unit Assembly Prior To Installation
There are 2 fl ue systems approved for use with the P33: the Regency ®... -
Page 10: Exterior Flue Termination Locations
(IV) A fl ue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free fl ow of air at the appliance is achieved. ® Regency P33 Gas Log Fireplace... -
Page 11: Regency ® Direct Flue System (Flex)
Notes: spacer 1) Liner sections should be continuous without any joints or seams. 6-7/8" ® 2) Only Flex pipe purchased from Regency (173mm) may be used for Flex installations. dia. Flue pipe Alternate Horizontal IMPORTANT Termination Caps If using any Cabinet Mantels with Part # 510956, 510958, 510962, 510964 and 510834 the wall thimble must be secured fi... -
Page 12: Installation Procedures
INSTALLATION INSTALLATION PROCEDURES ® for Regency Direct Flue System (Flex) 1) Locate the unit in the framing, rough in the *If this is an outside corner, the minimum distance between the fl ue and the outside gas (preferably on the right side of the unit) corner is 6"... -
Page 13: Simpson Dura-Vent Flueing
2 Wall Thimble inches. ® Adj.Pipe Length The Regency AstroCap is certified for installations using FPI fl ueing systems as well as 11" - 14-5/8" Simpson Dura-Vent® and Direct Vent GS. -
Page 14: Simpson Dura-Vent Flueing Components List
INSTALLATION SIMPSON DURA-VENT FLUEING COMPONENTS LIST All Simpson Dura-Vent components are available directly from Regency ® Part # Description 946-506/P Flue Guard (Optional) (AstroCap) Vert. Termination Kit includes 0/12 - 6/12 pitch adjustable fl ash- 640-530/P Riser Vent ing, storm collar, low profi le term. cap... -
Page 15: Flueing Arrangements - Vertical Terminations
Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles. Note: Must use optional fl ue adapter when using Simpson Dura-Vent pipe (Part # 510-994). ® Regency P33 Gas Log Fireplace... - Page 16 Vent Direct Flue GS fl ue systems for LPG, ULPG and NG. Maximum two 45 elbows allowed. • Flue must be supported at offsets. • Firestops are required at each fl oor level and whenever passing through a wall. • Maintain clearances to combustibles. ® Regency P33 Gas Log Fireplace...
-
Page 17: Flueing Arrangements - Horizontal Terminations
INSTALLATION FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS SIMPSON Dura-Vent DIRECT FLUE GS SYSTEM and REGENCY DIRECT FLUE SYSTEM (FLEX) (NG, LPG & ULPG with ULPG Burner) This diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 45... - Page 18 INSTALLATION FLUEING ARRANGEMENTS - HORIZONTAL TERMINATIONS SIMPSON Dura-Vent DIRECT FLUE GS SYSTEM and REGENCY DIRECT FLUE SYSTEM (FLEX) (ULPG with NG/LPG Burner) This diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 45 and one 90...
- Page 19 8 feet total 0.9m Max. 1.5m Min 1.8m Max. horizontal. Please note min. 1 foot be- 1.2m Max. 1.8m Min 2.1m Max. tween 90 elbows is 1.5m Max. 2.4m Min 2.4m Max. required. ® Regency P33 Gas Log Fireplace...
- Page 20 90 elbows is between 90 elbows is re- 1.2m 2.1m 1.5m 1.5m 1.5m required. quired. 1.5m 2.4m 1.8m 1.8m 1.8m For additional vertical fl ueing with 2 x 90 elbows, see "Vertical Terminations" sections. ® Regency P33 Gas Log Fireplace...
- Page 21 10 feet total 0.9m 1.2m 1.8m vertical and max. 8 feet total 1.2m 1.5m 2.1m horizontal. Please note min. 1 foot 1.5m 1.8m 2.4m between 90 elbows is 1.8m 2.1m 2.7m required. 2.1m 2.4m ® Regency P33 Gas Log Fireplace...
-
Page 22: Vertical Termination With Co-Linear Flex System
Pipe that clearances to combustibles are with Kit# maintained. 946-563 Air Intake Pipe Length Co-Linear Flex Flue Adaptor Adapter # 510-994 with Kit# 946-563 45 Elbow Inner Pipe Adapter with Kit# 946-563 ® Regency P33 Gas Log Fireplace... - Page 23 INSTALLATION Flueing Arrangements - Vertical Terminations with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. ® Regency P33 Gas Log Fireplace...
-
Page 24: Horizontal Terminations
Dura-Vent Installation instructions for details. pipe and high temperature silicone Do not attempt to enclose the Snorkel within the sealant to outer pipe on every twist- Diagram 4 lock joint. wall, or any other type of enclosure. ® Regency P33 Gas Log Fireplace... -
Page 25: Vertical Terminations
Flare nuts for copper lines and fl ex connectors are usually considered to meet this requirement. Diagram 4 Note: Apply sealant "Mill-Pac" to inner pipe and high temperature silicone sealant to outer pipe on every twist- lock joint. ® Regency P33 Gas Log Fireplace... -
Page 26: Pilot Adjustment
(Low) 0.33kPa at the pressure test point. Note: If you have an incorrect fl ame ® pattern, contact your Regency dealer for Note: To properly check gas pressure, both further instructions. inlet and manifold pressures should P33-LPG System Data be checked using the valve pressure ports on the valve. -
Page 27: Conversion Kit #433-968 From Ng To Lpg
11) Remove the black protection cap by hand from the high-low knob (Fig.1). Fig.3 Remove the 2 screws, push Burner Assembly to the left and lift out. Pull off the pilot cap to expose the pilot orifi ce. Fig. 1 ® Regency P33 Gas Log Fireplace... - Page 28 LPG Configuration Red o-ring visible Fig.5 17) Re-assemble the black protection cap (Fig. 6). Fig. 6 WARNING! Also check that the pilot and main burner injectors are appropriate for the gas type. ® Regency P33 Gas Log Fireplace...
-
Page 29: Conversion Kit #434-967 From Ng To Ulpg
Assembly to the left and lift out. 15) Using the Allen wrench as shown in Fig.4, rotate the screw clockwise until snug, do not overtighten. Pull off the pilot cap to expose the pilot orifi ce. Fig. 1 Fig.4 ® Regency P33 Gas Log Fireplace... - Page 30 17) Re-assemble the black protection cap These instructions must (Fig. 6). be left with the appliance. Fig. 6 WARNING! Also check that the pilot and main burner injectors are appropriate for the gas type. ® Regency P33 Gas Log Fireplace...
-
Page 31: Conversion Kit #434-965 From Ng To Ulpg
(Fig.1). 15) Using the Allen wrench as shown in Fig.4, rotate the screw clockwise until snug, do not overtighten. Pull off the pilot cap to expose the pilot orifi ce. Fig.4 Fig. 1 ® Regency P33 Gas Log Fireplace... - Page 32 17) Re-assemble the black protection cap These instructions must (Fig. 6). be left with the appliance. Fig. 6 WARNING! Also check that the pilot and main burner injectors are appropriate for the gas type. ® Regency P33 Gas Log Fireplace...
-
Page 33: Optional Brick Panels
Cutouts 5) Slide the Top Brick Panel into position and slide the Top Brick Retaining clips so that they hold the Top Brick Panel in place and tighten down the screws. 2nd Grate Tab ® Regency P33 Gas Log Fireplace... - Page 34 Cutout 7) Position Log 252 across the cutouts in Logs 254 and 253. The notch in the bottom right end fi tting against the 5th grate tab. 5th Grate Tab ® Regency P33 Gas Log Fireplace...
-
Page 35: Standard Flush Door
Diagram 1 Diagram 2 tach trim to the top and bottom of Flush door. Note: Top and bottom louvers are different. Diagram 1 Diagram 2 ® Regency P33 Gas Log Fireplace... -
Page 36: Wall Thermostat
INSTALLATION WALL THERMOSTAT REMOTE CONTROL OPTIONAL WALL SWITCH Use the Regency ® Remote Control Kit approved A wall thermostat may be installed if desired, for this unit. Use of other systems may void 1) Run the supplied 15' (4.5m) of wire through connect the wires as per the wiring diagram. -
Page 37: Wiring Diagram
Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to dis- connection when servicing controls. Wiring errors can cause improper and dangerous operation. ® Regency P33 Gas Log Fireplace... -
Page 38: Operating Instructions
You may shut off the pilot during prolonged non use periods to conserve fuel. 1) Turn OFF the flame switch. 2) Push in gas control knob slightly and turn to "OFF" position. DO NOT REMOVE THIS INSTRUCTION PLATE 918-253a ® Regency P33 Gas Log Fireplace... -
Page 39: Operating Instructions
CLEAN THE GLASS WHILE IT IS HOT. Note: Aeration Adjustment should only be until the pilot lights up. Continue to hold the performed by an authorized Regency ® control knob in for about 20 seconds after Note: When the glass is cold and the... -
Page 40: Maintenance
3) The heater is fi nished in a heat resistant your fan speed control. paint and should only be refi nished with heat BRASS LOUVERS/TRIM ® resistant paint. Regency uses StoveBright Burner Tray: Paint - Metallic Black #6309. The burner tray is positioned directly under the The 24 carat gold-plated or brass fi... -
Page 41: Thermopile / Thermocouple
Flush Front (Part # 936-155). DOOR GLASS Bay Glass Replacement ® Your Regency fi replace is supplied with high temperature, 5 mm Neoceram ceramic glass that 1) Remove the door from the unit and place will withstand the highest heat that your unit will on a soft surface to prevent scratching. -
Page 42: Removing Valve
17) Close the door and replace the louvers. 18) Fire up the unit again and check for proper fl ame appearance and glow on logs. Valve Tray Assembly screws Diagram 2: Rear Log Stand & Valve Tray Assembly ® Regency P33 Gas Log Fireplace... -
Page 43: Parts List
47) 904-586 Knob - Speed Control 104) 690-022F Cover Plate 510-994 Dura-Vent Adaptor 918-537 Manual 433-968 Conversion Kit - NG to LPG 434-967 Conversion Kit - NG to ULPG *Not available as a replacement part. ® Regency P33 Gas Log Fireplace... -
Page 44: Burner & Log Assembly
82) 433-024 Burner Grate Assembly - NG/LPG 83) * Rear Log Support Bracket - NG/LPG 85) 431-930 Log Set 86) 430-097 Air Defl ector-Left 87) 433-018 Air Defl ector-Right *Not available as a replacement part. ® Regency P33 Gas Log Fireplace... -
Page 45: Flush Front & Louvers
135) 940-088/P Glass (Flush) Screw - #8 x 1/2" 137) 904-691 U-Clip ® 139) 936-155 Glass Gasket (Tadpole) 179) 948-216 Regency Logo Plate 140) 948-042 Spring Hinge - Black *Not available as a replacement part. ® Regency P33 Gas Log Fireplace... -
Page 46: Bay Front & Louvers
107) 936-243 Glass Gasket 129) 948-042 Hinge ® 108) 940-078/P Center Glass 131) 948-216 Regency Logo Plate 110) * Bay Door Frame 111) 432-905 Bay Brick Panel - Standard Brown *Not available as a replacement part. 432-906 Bay Brick Panel - Standard Red... -
Page 47: Warranty
It is the responsibility of the installer to ensure that the appliance is fi ring as per rating plate. Any part or parts of this unit which in our judgement show evidence of such defect will be repaired or replaced at Regency ®... - Page 48 Printed in Canada © Copyright 2010 FPI Fireplace Products International Ltd. All rights reserved.
