- Page 1 I30VD VariFocal Dome Camera Quick Operation Guide UD.6L0201B1164A02...
- Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to the MicroView I30VD dome camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 I30VD Network Dome Camera·Quick Operation Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 I30VD Network Dome Camera·Quick Operation Guide EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.
- Page 5 I30VD Network Dome Camera·Quick Operation Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 6 I30VD Network Dome Camera·Quick Operation Guide To reduce the risk of fire or electrical shock, do not expose this product to rain or moisture. This installation should be made by a qualified service person and should conform to all the local codes.
- Page 7 I30VD Network Dome Camera·Quick Operation Guide Do not place the camera in extremely hot, cold temperatures (the operating temperature should be between -30°C ~ 60°C), dusty or damp environment, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is required for a proper operating environment.
-
Page 8: Table Of Contents
I30VD Network Dome Camera·Quick Operation Guide Table of Contents 1 Overview ......................9 2 Installation ...................... 11 2.1 Disassembling ................11 2.2 Mounting ..................12 2.2.1 Ceiling mounting ..............12 2.2.2 Ceiling mounting with gang box ........... 16 2.2.3 Wall Mounting ..............18 2.3 Image and Focus Adjusting ............. -
Page 9: Overview
I30VD Network Dome Camera·Quick Operation Guide 1 Overview Figure 1-1 Overview Table 1-1 Overview Description Bubble Black Liner Reset Button AUX Video Output Interface Serial Port... - Page 10 I30VD Network Dome Camera·Quick Operation Guide Description Power interface Ethernet interface Adapter Plate Lens...
-
Page 11: Installation
I30VD Network Dome Camera·Quick Operation Guide 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. -
Page 12: Mounting
I30VD Network Dome Camera·Quick Operation Guide Black Liner Bubble Screws Figure 2-1 Open the Bubble and Remove the Black Liner 2.2 Mounting 2.2.1 Ceiling mounting Steps: 1. Disassemble the camera. Refer to the section 2.1. 2. Attach the drill template (supplied) to the place where you want to fix the camera. - Page 13 I30VD Network Dome Camera·Quick Operation Guide 4. If you want to route the cables inside the ceiling, drill a cable hole in the ceiling according to the drill template. Skip this step if you want to route the cables on the surface of the ceiling.
- Page 14 I30VD Network Dome Camera·Quick Operation Guide 9. Adjust the image and focus. Please refer to the section 2.3 for more detailed information. 10. Install the black liner back to the camera. 11. Align the bubble to the mounting base and fix it by tightening the screws as shown in Figure 2-4.
- Page 15 I30VD Network Dome Camera·Quick Operation Guide Water-proof Plug Side Outlet Figure 2-5 Remove the water-proof plug 2. Route the power cable and network cable through the side outlet to the conduit. 3. Align and rotate clockwise the conduit to the side outlet tightly.
-
Page 16: Ceiling Mounting With Gang Box
I30VD Network Dome Camera·Quick Operation Guide For wall mounting, position the side outlet directly downward for water proofing. Downward Figure 2-7 Side Outlet Direction 2.2.2 Ceiling mounting with gang box Steps: 1. Disassemble the camera. Refer to the section 2.1. - Page 17 I30VD Network Dome Camera·Quick Operation Guide Figure 2-8 In-ceiling Mount 4. Route the cables through the hole in the center of the mounting base. 5. Align the camera with the mounting base. 6. Tighten the screws to secure the camera with the mounting base.
-
Page 18: Wall Mounting
I30VD Network Dome Camera·Quick Operation Guide 9. Install the inner black liner back to the camera. 10. Align the lower dome with the camera. 11. Tighten the screws to secure the lower dome with the camera as shown in Figure 2-10. - Page 19 I30VD Network Dome Camera·Quick Operation Guide 4. Secure the mounting base to the mounting adapter with four screws. Mounting Adapter Figure 2-11 Install the Mounting Adapter Mounting Base Figure 2-12 Secure Mounting Base...
- Page 20 I30VD Network Dome Camera·Quick Operation Guide 5. Route the cables through the hole in the center of the wall mount. 6. Align the camera with the mounting base. 7. Tighten the set screws to secure the camera with the mounting base.
-
Page 21: Image And Focus Adjusting
I30VD Network Dome Camera·Quick Operation Guide 10. Install the black liner back to the camera. 11. Align the bubble with the camera and tighten the screws to fix the bubble. Black Liner Lower Dome Figure 2-14 Secure Black Liner and Bubble 2.3 Image and Focus Adjusting... - Page 22 I30VD Network Dome Camera·Quick Operation Guide 4). Rotate the lens table to adjust the azimuth angle of the image. Panning Tilting Rotation Figure 2-15 3-axis Adjustment 2. Zoom and focus adjustment. 1). View the camera image using the monitor.
- Page 23 I30VD Network Dome Camera·Quick Operation Guide Lever Lever Figure 2-16 Lens Adjustment...
-
Page 24: Setting The Network Camera Over The Lan
I30VD Network Dome Camera·Quick Operation Guide Setting the Network Camera over the LAN Purpose: To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then install the MonitoringCenter software to search and change the IP address of the network camera. - Page 25 I30VD Network Dome Camera·Quick Operation Guide After launch MonitoringCenter software, it automatically searches the online devices every 15 seconds from the subnet where your computer locates. It displays the total number and information of the searched devices in the Online Devices interface.
- Page 26 I30VD Network Dome Camera·Quick Operation Guide 4). Enter the admin password in the Manager Password field and click to save the changes. Figure 3-3 Modify Network Parameters ● The default value of the IP address is “192.0.0.64”. The default user name is “admin”, and password is “12345”.
-
Page 27: Accessing Via Web Browser
I30VD Network Dome Camera·Quick Operation Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher... - Page 28 I30VD Network Dome Camera·Quick Operation Guide Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in.
- Page 29 I30VD Network Dome Camera·Quick Operation Guide Figure 4-2 Download Plug-in Figure 4-3 Download Plug-in Figure 4-4 Install Plug-in...
- Page 30 I30VD Network Dome Camera·Quick Operation Guide Figure 4-5 Install Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. For detailed instructions of further configuration, please refer to the user manual...
- Page 31 I30VD Network Dome Camera·Quick Operation Guide...
