iSERIES I30VD Network Dome Camera·Quick Operation Guide
4. If you want to route the cables inside the ceiling, drill a cable hole in the ceiling
according to the drill template. Skip this step if you want to route the cables
on the surface of the ceiling. Refer to Conduit Installation on the Side for side
cable routing.
5. Attach the camera to the ceiling by aligning the holes of the back box with the
holes on the ceiling.
6. Secure the camera with the supplied screws as shown in Figure 2-3.
7. Route the cables through the cable hole.
8. Connect the video output connector to the monitor. Connect the power
connector to the power supply.
Figure 2-3 Secure the Camera
13
Back Box
Screws
