iSERIES I30VD Network Dome Camera·Quick Operation Guide
9. Adjust the image and focus. Please refer to the section 2.3 for more detailed
information.
10. Install the black liner back to the camera.
11. Align the bubble to the mounting base and fix it by tightening the screws as
shown in Figure 2-4.
Conduit Installation on the Side
If you want to route the cables from side of the camera, you need to follow the
steps below to install a conduit for cable routing.
Steps:
1. Rotate the water-proof plug counterclockwise to remove it from the camera.
Figure 2-4 Secure Black Liner and Bubble
