- Page 1 A13D Dome Camera User Manual...
- Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to MicroView A13D dome camera This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 A13D Dome Camera·User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 A13D Dome Camera·User Manual EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.
- Page 5 A13D Dome Camera·User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 6 A13D Dome Camera·User Manual When the product is mounted on wall or ceiling, the device shall be firmly fixed. If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
- Page 7 A13D Dome Camera·User Manual To avoid heat accumulation, good ventilation is required for operating environment. Keep the camera away from liquid while in use. While in delivery, the camera shall be packed in its original packing, or ...
-
Page 8: Table Of Contents
A13D Dome Camera·User Manual Table of Contents 1 Introduction ...................... 8 1.1 Product Features ................8 1.2 Overview ..................9 2 Installation ....................100 2.2 Ceiling Mounting for Camera ............111 2.6 Power Supply ................. 13... -
Page 9: Introduction
A13D Dome Camera·User Manual 1 Introduction 1.1 Product Features This series of camera adopts new generation sensor with high sensitivity and advanced circuit design technology. It features high resolution, low image distortion and low noise, etc., which makes it suitable for surveillance system and image processing system. -
Page 10: Overview
A13D Dome Camera·User Manual 1.2 Overview Enclosure Trim Ring Power Cable Mounting Base Video Cable Figure 1-1 Overview of Camera... -
Page 11: Installation
A13D Dome Camera·User Manual 2 Installation Before you start: Make sure that the device in the package is in good condition and all the assembly parts are included Make sure that all the related equipment is power-off during the installation. -
Page 12: Ceiling Mounting For Camera
A13D Dome Camera·User Manual 2.1 Ceiling Mounting for Camera Steps: Drill the screw holes and the cable hole according to the drill template. Screw Hole Screw Hole Screw Hole Figure 2-1 Drill Template of Type II Camera Fix the mounting base to the ceiling with the supplied screws. - Page 13 A13D Dome Camera·User Manual Route the cables to the cable hole and connect the corresponding power cable and video cable. Fix the camera to the mounting base. Fit the enclosure to camera. Enclosure Figure 2-3 Secure the Camera/Enclosure/Trim Ring Adjust the surveillance angle according to the figure below.
- Page 14 A13D Dome Camera·User Manual 2.2 Power Supply Figure 2-5 The Power Cable and the Video Cable Note: Please make sure that the power adapter is compatible with the camera, and the standard power supply is 12V DC. Please refer to the technical...
