- Page 1 A13VD VariFocal Dome Camera User Manual...
- Page 2 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to the MicroView A13VD varifocal dome camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 A13VD VariFocal Dome Camera · User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 A13VD VariFocal Dome Camera · User Manual EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.
- Page 5 A13VD VariFocal Dome Camera · User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 6 A13VD VariFocal Dome Camera · User Manual Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard. Please make sure that the plug is firmly connected to the power socket.
- Page 7 A13VD VariFocal Dome Camera · User Manual Do not place the camera in extremely hot, cold (the operating temperature shall be-40℃~+60℃), dusty or damp locations, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is required for operating ...
-
Page 8: Table Of Contents
A13VD VariFocal Dome Camera · User Manual Table of Contents 1 Introduction ...................... 8 1.1 Product Features ................8 1.2 Overview ..................9 2 Installation ...................... 10 2.5 Ceiling Mounting for Type V Camera..........11 2.6 Power Supply ................. 15... -
Page 9: Introduction
A13VD VariFocal Dome Camera · User Manual 1 Introduction 1.1 Product Features This series of camera adopts new generation sensor with high sensitivity and advanced circuit design technology. It features high resolution, low image distortion and low noise, etc., which makes it suitable for surveillance system and image processing system. -
Page 10: Overview
A13VD VariFocal Dome Camera · User Manual 1.2 Overview Zoom & Focus Camera Enclosure Lock Screw Trim Ring Video Cable Power Cable Figure 1-1 Overview of Camera... -
Page 11: Installation
A13VD VariFocal Dome Camera · User Manual 2 Installation Before you start: Make sure that the device in the package is in good condition and all the assembly parts are included Make sure that all the related equipment is power-off during the installation. -
Page 12: Ceiling Mounting For Type V Camera
A13VD VariFocal Dome Camera · User Manual 2.1 Ceiling Mounting for Camera Drill the screws holes and the cable hole on the ceiling according to the supplied drill template. Screw Hole Screw Hole Template Screw Hole Figure 2-1 Drill Template of Type V Camera Loosen the lock screw, and pull the clip plate outward to disassemble the camera from the mounting base. - Page 13 A13VD VariFocal Dome Camera · User Manual Figure 2-2 Disassemble the Camera Fix the mounting base to the ceiling. Figure 2-3 Fix the Mounting Base Route the cables to the cable hole and connect the corresponding cables. Install the camera to the mounting base by tightening the lock screw and pushing back the clip plate.
- Page 14 A13VD VariFocal Dome Camera · User Manual Clip Plate Figure 2-4 Install the Camera and the Enclosure Adjust the camera according to the figure below to get an optimum angle. 0~360° 0~75° 0~360°...
- Page 15 A13VD VariFocal Dome Camera · User Manual Figure 2-5 3-axis Adjustment Use the screwdriver to adjust the ZOOM screw and the FOCUS screw until you get the optimum image. Figure 2-6 Zoom and Focus Adjustment...
-
Page 16: Power Supply
A13VD VariFocal Dome Camera · User Manual 2.2 Power Supply Figure 2-7 The Power Cable and the Video Cable Note: Please make sure that the power adapter is compatible with the camera, and the standard power supply is 12V DC. Please refer to the technical...
