PM172 Quick Start Guide
4. In the Sampling Rate box, select a rate at which PAS updates data on
your screen when you continuously poll the device in the PAS Data
Monitor.
The communication protocol and port settings in PAS must match the settings
made in your device.

COM1 Settings

Code Parameter
Prot Communications protocol
Port Interface, depends on
rS
order
Addr Device Address
bAud Baud rate
dAtA Data format
H.Sh Handshaking (flow control)
rtS RTS mode

COM2 Settings

Code Parameter
Prot Communications protocol
rS Port Interface
Addr Address
bAud Baud rate
dAtA Data format and parity
12
Options
ASCII, rtu*, dnP3
232 = RS-232
485 = RS-485
422 = RS-422
dial = Dial-up Modem
Eth.= Ethernet
Modbus: 1 (default) -247
DNP3.0: 0 (default) -255
300 - 115,200 bps (19,200 bps*)
7E, 8E (7/8 bits, even parity), 8N* (8 bits, no parity)
7E data format should not be used with the Modbus RTU and DNP3
protocols
nonE*=no flow control
SOFt=software (XON/XOFF)
HArd=hardware (CTS)
nonE* = not used
Forc = RTS is permanently asserted
CtrL = RTS is asserted during the transmission
Options
Rtu* = Modbus RTU
ASCII = Modbus ASCII
dnP3 = DNP3
485* = RS-485
422 = RS-422
Modbus: 1*-247
DNP3: 0–65532
300-115,200 bps
(19,200 bps*)
7E, 8N*, 8E
Description
ASCII, Modbus RTU or DNP3.0 protocol
For non-serial interfaces this is not changeable,
it is automatically detected by the meter
Description
The communications protocol supported by the
port
Device network address
The port baud rate.
7E data format should not be used with the
Modbus RTU and DNP3 protocols
Series PM172 Powermeters
