- Page 1 Clara Product Manual High Resolution Video Baby Monitor KBHP5 Proudly Designed in Canada CAUTION: Keep small parts away from children.
-
Page 2: Thank You
Thank You For bringing Levana home! Your feedback is essential to helping us make our products the best they can be for all parents. Please share your Levana story with us! www.mylevana.com /mylevana @mylevana blog.mylevana.com... -
Page 3: Safety Instructions & Disclaimers
Failure to do so can be fatal. Power Source: LEVANA® highly recommends the use of an Uninterruptible Power Supply (UPS) with surge protection when plugging in the camera and monitor. This product should only be used with the AC power adapters included. -
Page 4: Disclaimers
Battery life of 8 hours based on Power Save mode. Battery lasts an average of 4 hours with continuous audio/video usage. • © 2018 LEVANA®. All rights reserved LEVANA® logo, Clara™ and other LEVANA® marks may be registered. All other Trademarks are the property of their respective owners. -
Page 5: Compliance Statements
COMPLIANCE STATEMENTS FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Support
Canada, L2H 1J9 USA 14225 Product Manual Feedback At Levana, we’re always looking to improve your experience. Please share any suggestions for this product manual to help us continue on this journey. CLICK HERE FOR FEEDBACK SURVEY LINK Help Videos... -
Page 7: Warranty Terms
WARRANTY TERMS LEVANA® products are guaranteed for a period of one year from the date of purchase against defects in workmanship and • materials. This warranty is limited to the repair, replacement or refund of the purchase price at LEVANA®’s options. -
Page 8: Table Of Contents
TABLE OF CONTENTS Menu Functions Thank You ...................... 1 Power Save....................18 Safety Instructions & Disclaimers Lullabies ....................19 Safety Instructions ................. 2 Feeding Timer ..................19 Disclaimers....................3 Camera select (Single View-Active Camera) ........20 Compliance Statements ................4 Split Screen ..................... -
Page 9: What's Included
WHAT’S INCLUDED 5” High Resolution Baby Video Monitor • 2 Rechargeable Battery Packs (Installed) • • Pan/Tilt/Zoom Night Vision Camera 2 Power Adapters (Monitor and Camera) • Camera Mounting Hardware • Quick Start Guide • 1 Year Warranty • • Lifetime Customer Support Adding Cameras Your Clara monitor is expandable up to 4 cameras and is compatible with Clara PTZ cameras. -
Page 10: Buttons & Features
BUTTONS & FEATURES Power ON/OFF (Top) Talk to Baby Night Vision Sensor Power Input (Side) Exit/Back Microphone Microphone Temperature Sensor (Back) Volume-/+ (Side) Stand (Back) Power LED (Side) Antenna (Back) Navigation Arrows Power Input (Side) Power ON/OFF (Side) Pairing Button (Bottom) Menu/OK Speakers... -
Page 11: Getting Started
If the camera is not automatically paired after • • screen will appear after the Levana splash screen. setup is complete you will need to pair it See page 11 for Introduction instructions. manually. See page 22 for pairing instructions. -
Page 12: Introduction Screens
GETTING STARTED Introduction Screens When you turn on your monitor for the first time and after a Factory Reset, the Introduction will appear on the screen. This feature gives you the option to create settings and to learn more about how your monitor works. •... -
Page 13: Status Bar
GETTING STARTED Status Bar SIGNAL STRENGTH CAMERA MODES FEATURES Active Camera Lullabies ONM High (# shows which camera is active) Temperature Average 22°c Sequence Mode (Active Camera Only) Camera Unpaired Very Low VOLUME LEVELS SOUND INDICATORS BATTERY LEVELS Very High 100% High 50-75%... -
Page 14: Setup
SETUP Monitor Placement Use the retractable stand on the back of the monitor to place it on a table top. When not in use, clip the stand back in place so that the bracket is flush with the back of the monitor. Camera Placement The camera can be placed on a table top or hung on the wall above the area being monitored. - Page 15 SETUP WALL PLACEMENT Important: Before drilling, check the camera placement and reception. Ensure you are hanging the camera no less than 3 ft away from baby’s crib. Pre-drill one hole in the wall using a drill bit that meets the size of the screw.
-
Page 16: Features
FEATURES Clara comes with a PTZ (Pan/Tilt/Zoom) camera view 300° horizontally and 110° vertically from the center position. You can also zoom in 2x from the Camera Select menu. Pan/Tilt Zoom From the View screen press the Navigation Arrows UP/DOWN Zoom is available through the Camera Select option. -
Page 17: Volume Controls
FEATURES Volume Controls MONITOR CAMERA Use the + / - buttons on the side of the monitor to adjust The camera volume is adjusted from the Lullabies menu for the volume. As you press the buttons the volume level will all sounds. -
Page 18: Talk To Baby Tm
FEATURES Talk To Baby Accessing the Menu 12:45 22°c Power Save Lullabies Feed/Nap Timer Camera Settings Support With the simple press of a button, you can talk to your child at any time, without entering the room, through the Active Camera. -
Page 19: Menu Functions
MENU FUNCTIONS Power Save Power Save Use the Power Save features to extend the battery life of your monitor. SLEEP MODE AUDIO ONLY When selected, the video monitoring will shut off when no When selected, the video monitoring will shut off and allow sound is heard. -
Page 20: Lullabies
MENU FUNCTIONS Lullabies Feeding Timer Feed/Nap Timer Lullabies Select from the 2 Lullabies, 2 Nature Sounds or White Noise to Set a Timer to remind you when it's time for baby's next feeding. help soothe baby to sleep. Set timers for playing sounds and The Timer can be set to alert once or be repeated at every time control the camera volume levels. -
Page 21: Camera Select (Single View-Active Camera)
MENU FUNCTIONS Feeding Timer Continued Camera Feed/Nap Timer Camera Change camera views, pair/un-pair cameras, and set night vision ON SCREEN ALERT CAMERA SELECT (SINGLE VIEW-ACTIVE CAMERA) Camera Select Select a single camera to view on screen. When selected this will 12:45 22°c be the Active Camera. -
Page 22: Split Screen
MENU FUNCTIONS Camera Continued Camera SPLIT SCREEN QUAD SCREEN Split Screen Quad Screen Select up to 2 cameras to view on screen. Both cameras can Select up to 4 cameras to view on screen. All cameras be viewed however the monitor will only play sound through can be viewed however the monitor will only play sound the Active Camera. -
Page 23: Camera Pairing
MENU FUNCTIONS Camera Continued Camera CAMERA PAIRING Camera Pairing Pair camera(s) manually if the camera does not pair automatically to the monitor, to add cameras, or to un-pair a camera. Pairing Press and hold the Pairing button on the bottom of the Open the Menu, choose Camera, and press OK. -
Page 24: Night Vision
MENU FUNCTIONS Camera Continued Camera NIGHT VISION Night Vision Your PTZ camera is equipped with invisible IR (Infrared) LEDs which keep your baby's room dark but allow you to see with perfect clarity. The LEDs are located on the front of the camera and allow you to see up to 12 ft in complete darkness so you can check on your baby at any time of night. -
Page 25: Settings
MENU FUNCTIONS Settings Settings LANGUAGE BRIGHTNESS Language Brightness Select the menu language. Your monitor supports English, Adjust the brightness of the monitor screen. Lowering the French or Spanish. The Language option is included in the brightness of the monitor can help to increase battery life. Introduction screens as well. -
Page 26: Time Set
MENU FUNCTIONS Settings Continued Settings TIME SET FACTORY RESET Factory Reset Time Set Select to change the time on your monitor. This is included in Allows you to restore the monitor back to the factory default the initial Introduction screens. setting. -
Page 27: Temperature
MENU FUNCTIONS Settings Continued Settings TEMPERATURE Temperature Set temperature monitoring on your cameras to be alerted when baby's room becomes too hot or cold. This is monitored by the camera and alerts are sent to the monitor. Keep the camera temperature sensor away from heat sources and windows to ensure an accurate reading. -
Page 28: Auto Motion Tracking
MENU FUNCTIONS Settings Continued Settings AUTO MOTION TRACKING Auto Motion Tracking The Auto Motion Tracking feature enables your camera to move with your busy toddler. As your child moves, the PTZ camera will follow up to 300° horizontally and 110° vertically so you can see them as they move around the room. Once your child is out of view range the camera will remain stationary until motion is detected again. -
Page 29: Support
MENU FUNCTIONS Support Support INTRODUCTION FAQs Introduction Provides screens for changing Language/Time and a Provides a list of the most frequently asked questions with description of the Button Functions. This is included in the instructions. This is included in the initial Introduction initial Introduction screens. -
Page 30: Battery Installation
BATTERY INSTALLATION Your monitor uses a Nickel Metal Hydride (NiMH) rechargeable battery instead of Lithium Ion which provides increased safety and no toxic metals. The 2 battery packs are already installed when you purchase the monitor. Replacing Battery Packs Press the release clip down to pop open the battery cover. Remove the battery packs (2 plugs) and unplug the wires to replace. -
Page 31: Troubleshooting
TROUBLESHOOTING ISSUE POSSIBLE REASON POSSIBLE SOLUTION • Monitor/Camera may not be powered On. • Confirm the monitor and camera are powered On. MONITOR/CAMERA NOT • Monitor battery may be depleted. • Try recharging the monitor battery. FUNCTIONING • Power adapters may not be properly connected. •... - Page 32 TROUBLESHOOTING ISSUE POSSIBLE REASON POSSIBLE SOLUTION • Try increasing the amount of light in the room to turn off Night PICTURE IS BLACK AND WHITE • Night Vision may be enabled. Vision. • Check the Night Vision setting in the Camera menu. •...
-
Page 33: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS QUESTION ANSWER Can I hear more than one camera at the same • The monitor will only play sounds from the Active Camera unless you are using Sequence Mode. In Sequence Mode time? the sound will play through each camera for 10 second intervals. •... -
Page 34: Specifications
SPECIFICATIONS Maximum Monitors Supported Split Screen Monitor Type Sequence Mode Screen Size 5” Speaker Resolution 800 X 480 Microphone Frame Rate 25 Frame Per Second (FPS) at Talk to Baby™ optimal range Lullabies (2 lullabies, 2 nature sounds, 1 white noise) LCD Brightness Adjustable –... - Page 35 SPECIFICATIONS Camera(s) Image Sensor CMOS IR Wavelength 940 nm Resolution 720p Battery Operable Cameras Supported (per monitor) Up to 4 Microphone Viewing Angle Speaker Focal Length Temperature Sensor Optimal Focus Distance Housing Material ABS Plastic Wall Mountable Yes (1 screws and anchor) Range of Motion –...
- Page 36 Thank you for choosing Levana! To learn more about our products and accessories, please visit www.mylevana.com...
