Application Guide - Pairing The Smart Box
With the CSB040 smart box connected to the router, and the smart device (Phone
or tablet) connected via Wi-Fi to the same router, the app will pair using DHCP
connection. Once the IP address has been issued it will be saved as a static IP.
If the name and IP address is known for the router, the details can be added manually.
To automatically start searching for the smart box, select 'AUTO'. The IP address of
the smart box will appear when found.
Select the IP address listed to set the address to static and to assign an identification
name. The name will be saved locally to the smart device and not the smart box.
The IP address is set to static to prevent the IP address potentially changing after a
power outage or re-boot of the smart box and router.
Allocate the name and when listed press on the grey circular dot to assign.
Previous
Next Page
9
Next
Contents
The grey circular dot
changes to blue, this
confirms the pairing
with the smart box and
the smart device is now
connected.
Up to 6 smart boxes can
be assigned.
Select 'Next' to start
entering rooms, elements
and scenes.
