Application Guide - Creating Scenes - continued
3b. Dimming receiver selected.
A. The initial screen starts up with the dimming arc.
Simply press or press and slide around the arc to set the required lighting level. Select
back to save the setting and return back to the scene listing.
B. In the top right corner, by selecting 'Next' (Android) or 'More' (iOS) the screen
progresses to time settings for dimming up to maximum or down to minimum.
The settings relate to minutes & seconds (59 minutes, 59 seconds maximum).
Decrease - Time to dim down to off (sunset)
Increase - Time to dim up to 100% (sunrise)
Add the required time for either option and press the 'decrease' or 'increase' button
so highlighted in blue to assign.
Previous
Next Page
Select back to save the setting and return back to the
scene listing.
The receiver / appliance setting on the scene listing will
change.
A blue tick replaces the 'X', with additional
(Android).
Select the blue tick to remove the selection from the
scene or icon to change the receiver setting.
15
