Schedules - Create - Select Elements & Functions
To create time schedules simply add the schedule name, select the smart box and the
required elements (must be of the same function, e.g. all switching receivers).
Shutter elements / receivers:
• RFJA-12B/230V and RFJA-12B/24V
• Functions: Select UP (open) for times assigned and
will automatically be down between schedules.
• Selecting 'DOWN' will not display on the time bar.
For dimming receivers see the following page.
Previous
Next Page
iOS
iOS
With the elements selected the 'Functions available'
tab lists the functions that are available for the type of
receiver selected (not used to assign to schedule).
The actual function required is assigned when adding
the schedule information.
Switching elements / receivers:
• RFSC-61, RFSA-61B, RFSAI-61B, RFSA-61M,
RFSA-62B and RFSA-66M
• Functions: Select ON for times assigned and will
automatically be off between schedules.
• Selecting 'OFF' will not display on the time bar.
27
