Schedules - Create - Assign Day, Times & Function cont'd
Day, time and function input screen (dimming elements)
With the day, times and dimmed levels added, pressing save will then display the
weekly overview screen with the time selection displaying on the time bar.
Press 'save' on the time bar screen will then save all set times and functions.
Dimming
When selecting the dimming level, each of the four percentages displays a different
colour on the time bar:
0% - Nothing displayed
Level 1 - (20% default): Green
Level 2 - (50% default): Orange
Level 3 - (70% default): Red
Level 4 - (100% default): Blue
