Application Control - Shutter
The current status icon of the shutter receiver is displayed.
Icon pale grey outline.
Receiver element is
either not powered, out of
range or address input is
incorrect.
The Click Smart shutter receiver features UP (open) and DOWN (close) options for
control with a 'STOP' button to assist where required.
• 'Auto' can only be enabled once time schedules have been setup which includes
this element/receiver.
• There is only one time setting which covers both UP and DOWN, press 'Set' to
save the time. We recommend setting the time for which creates the longest time
event. The inbuilt limit switch in the blind/curtain motor will prevent the motor and
blind from over-running.
• The visual on screen blind will animate to display its current status.
Previous
Next Page
Icon with white outline and
blind down.
Receiver element is within
range with the shutter in
the closed position.
38
Next
Contents
Icon with blue infill and
blind up.
Receiver element is within
range with the shutter in
the open position.
