Application Guide - Creating Scenes
Creating scenes enables multiple elements (receivers) to be added with each element
assigned its own function for that scene. With a single press all the set commands can
be carried out.
Example. The scene 'Reading' could be set up so the main lounge lights are dimmed
to 10% whilst the table lamp switches 'OFF' and the floor lamp (preferred for reading)
is switched 'ON'.
If necessary, 'Scenes' can be created or edited later if preferred.
To create scenes select 'ADD SCENES' to enter the Scenes menu or complete to
finish the application guide setup.
1. Assign the scene a name.
2. Select the smart box to be assigned. Choose the elements and function settings.
Fig. S1
Previous
Next Page
3. Choose from the list of receivers already added.
As each receiver/appliance is selected the function to be
carried out will need to be assigned.
The following pages will explain about each setting for:
• Switching receivers
• Dimming receivers
• Shutter receivers
13
