Schedules - Create - Select Elements & Functions - cont'd
Dimming elements / receivers:
RFDA-71B, RFDEL-71B and RFDAC-71B
Functions available: Four dimming levels (default 20, 50, 70 & 100%) allowing
the desired level to be set for a specified time period.
In between the assigned time schedules the light source will be off.
Selecting 'DOWN' will not display on the time bar.
Each of the four levels can be adjusted by pressing the level to be amended.
The control screen opens and the level can be adjusted in 10% increments.
Press the 'back' (Android) or 'X' (iOS) to save and return to the function screen.
Once the elements have been selected, select 'Next' to assign the days, times and
the element(s) function (dimmed level).
