Specifications

Video camera
recorder
System
Video recording system
Two rotary heads, Helical
scanning, FM system
Audio recording system
Rotary heads, FM system
Video signal
NTSC color, EIA standards
Usable cassette
8 mm video format cassette
(standard 8 mm)
Recording/Playback time
SP mode: 2 hours (P6-120)
LP mode: 4 hours (P6-120)
Fastforward/rewind time
Approx. 5 min. (P6-120)
Image device
CCD (Charge Coupled Device)
Viewfinder
Electronic viewfinder
CCD-TRV12/TRV22/
TRV112/TRV212:Black and white
CCD-TRV33:Color
Lens
Combined power zoom lens, F1.8–
2.8
Filter diameter 1 1 ⁄ inches (37 mm)
2
CCD-TRV12/TRV22/TRV112/
TRV212:13x (Optical), 26x (Digital)
CCD-TRV33:13x (Optical), 52x
(Digital)
Focal distance
f = 7 ⁄ – 2 5 ⁄ inches (5.3 – 68.9 mm)
32 8
When converted to a 35mm still
camera
CCD-TRV12/TRV112:
1 9 ⁄ – 18 1 ⁄ inches (38 – 494mm)
16 2
CCD-TRV22/TRV33/TRV212:
7 1
1 ⁄ – 22 ⁄ inches (46 – 598 mm)
8 4
Color temperature
Auto
Minimum illumination
CCD-TRV12/TRV112:
0.6 lux at F 1.8
CCD-TRV22/TRV33/TRV212:
2 lux at F 1.8
Illumination range
CCD-TRV12/TRV112:
0.6 to 100,000 lux
CCD-TRV22/TRV33/TRV212:
2 to 100,000 lux
Recommended illumination
More than 100 lux
46
LCD screen
2.5 inches measured diagonally
1
2 x 1 ⁄ inches (50.3 x 37.4 mm)
2
On-screen display
TN LCD/TFT active matrix
method
Total dot number
61,380 (279 x 220)
Input and Output connectors
Video output
Phono jack, 1 Vp-p, 75 ohm,
unbalanced
Audio output
Monaural, Phono jack, 327 mV, (at
load impedance 47 kilohm),
impedance less than 2.2 kilohm
RFU DC OUT
Special minijack, DC 5 V
Earphone jack
Mini-jack
LANC control jack
Stereo mini-minijack (ø 2.5 mm)
MIC jack
Minijack, 0.388 mV, low
impedance with 2.5 to 3 V DC
output, impedance 6.8 kilohm (ø
3.5 mm)
Speaker
Dynamic-speaker
General
Power requirements
7.5 V (AC power adaptor)
Average power consumption
During camera recording using
the LCD
CCD-TRV12/TRV112: 4.8W
CCD-TRV22/TRV33/TRV212:
4.9W
During camera recording using
the viewfinder
CCD-TRV12/TRV112: 3.7W
CCD-TRV22/TRV33/TRV212:
3.8W
Operating temperature
32°F to 104°F (0°C to 40°C)
Storage temperature
–4°F to +140°F (–20°C to +60°C)
Dimensions (Approx.)
4 1 ⁄ x 4 1 ⁄ x 8 3 ⁄ inches
2 4 8
(113 x 106 x 210 mm) (w/h/d)
CCD-TRV12/TRV22/TRV33/TRV112/TRV212 3-859-057-15.E
Mass (Approx.)
CCD-TRV12/TRV112: 1 lb 14 oz
(860g)
CCD-TRV22/TRV33/TRV212: 1 lb
14 oz (870g)
Excluding the battery pack,
lithium battery, cassette and
shoulder strap
2 lb 6 oz (1.1kg)
Including the battery pack NP-33,
lithium battery CR2025, cassette
P6-120 and shoulder strap
Microphone
Electret condenser microphone,
monaural type
Supplied accessories
See page 5.
AC power adaptor
Power requirements
110 – 240 V AC, 50/60Hz
Power consumption
AC-V16: 20 W
AC-V16A: 22 W
Output voltage
DC OUT in operation mode
AC-V16/V16A: 7.5 V, 1.8 A
Battery charge terminal
10 V, 1.1 A in charge mode
Application
Sony battery packs NP-
33(supplied), NP-60D, NP-C65,
NP-66H, NP-68, NP-78, NP-80,
NP-80D, NP-98, NP-98D
Operating temperature
32°F to 104°F (0°C to 40°C)
Storage temperature
–4°F to +140°F (–20°C to +60°C)
Dimensions (Approx.)
5 11
6 ⁄ x 1 ⁄ x 3 inches (166 x 43 x 75
8 16
mm) (w/h/d)
including projecting parts and
controls
Mass (Approx.)
AC-V16: 15 oz (420 g)
AC-V16A: 16 oz (450 g)
Design and specifications are
subject to change without notice.
