Removing dust from inside the viewfinder
(1) Remove the screw with a screwdriver (not supplied). Then, while sliding the
RELEASE knob, turn the eyecup in the direction of the arrow and pull it out.
(2) Clean the surface with a commercially available blower.
1
To reattach the eyecup
(1) Align the groove on the eyecup with the • mark on the barrel.
(2) Turn the eyecup in the direction of the arrow. Then, replace the screw.
1
Caution
Do not remove any other screws. You may remove only the screw to remove the
eyecup.
2
2
CCD-TRV12/TRV22/TRV33/TRV112/TRV212 3-859-057-15.E
39
