Video Camera
Recorder

Operating Instructions

Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
Owner's record
The model and serial numbers are located on the bottom. Record
the serial number in the space provided below. Refer to these
numbers whenever you call upon your Sony dealer regarding this
product.
Model No. CCD-
Serial No. ___________________
CCD-TR930
©1997 by Sony Corporation
Model No. AC-
Serial No. __________________
3-859-496-11 (1)
