- Page 1 Installation and User Guide PHP400 Help Point VoIP version 48V DC power supply IMPORTANT THIS PRODUCT MUST BE CONFIGURED PRIOR TO INSTALLATION PLEASE READ THIS GUIDE FIRST GAI-TRONICS A division of Hubbell Ltd. Doc. No. 502-20-0130-001 Iss 4. Jan 2016. (CN39819-001)
-
Page 2: Table Of Contents
CONTENTS Safety and Care Information ..................3 Product Description and Features ................3 Before Installation ..................... 5 3.1. Opening the Unit ................... 5 3.2. Initial Network set-up ..................5 3.3. Site requirements ..................6 Installation and dimensions ..................6 4.1. General ...................... -
Page 3: Safety And Care Information
Product Description and Features This manual describes the voice over internet protocol (VoIP) version of the GAI-Tronics 400mm circular Help Point. This product is based on the standard VoIP product range and has been specifically configured for use on rail platforms, with features including: Weather and vandal resistant casing •... - Page 4 Top cable entry point Security fixings Speaker (4 positions) Pushbutton Raised text / Braille legend Call progress Microphone Lower cable entry point Front section Induction loop Induction loop coil amplifier Induction loop audio feed VoIP module 48-12V DC-DC converter Serial connector Incoming power...
-
Page 5: Before Installation
Before Installation IMPORTANT THESE UNITS MUST BE CONFIGURED BEFORE THEY ARE INSTALLED. All units have identical settings as factory defaults, so each one must be individually configured to give it a unique identity on the network. This may be difficult to do after the units are installed. -
Page 6: Site Requirements
Refer to the VoIP configuration guide 502-20-0119-001 for full details on all settings. The configuration guide is available from www.gai-tronics.org/support/voip-support/ To configure the unit it must first be powered, but note that the VoIP module itself can be powered via PoE if required. External power is only necessary because of the induction loop system. -
Page 7: Units Dimensions And Weight
Units dimensions and weight 4.2. Overall diameter 405mm Depth (rear surface to front face) 88mm Pushbutton height from front face 10mm Unit weight 6.5kg Mounting centres 4 x 7mm holes on 145 x 270mm centres, see drawing 112-11-0081-001 appended to this manual. - Page 8 4. Select fixing screws or bolts appropriate to the type of wall or surface, suitable to support the unit. Drill fixing holes to suit. 5. Separate the front and rear sections of the Help Point, taking care to disconnect interconnecting cables as described in section 3.1. 6.
-
Page 9: Connections
Connect a 48V DC power supply to the terminal block as shown on the connection label. If a 48V power supply is not available, GAI-Tronics can supply a suitable unit, see spare parts (section 8). One power supply cannot supply more than one PHP400 - a separate, isolated supply must be provided for each unit.. -
Page 10: Connections To The Voip Module
Connections to the VoIP module 5.3. Make the appropriate connections as shown on the diagrams below. Back-box Serial port RJ45 Network connector Output connections (under back-box) 48Vdc IP1 IP2 IP3 IP4 Power connections Input connections Clamping position Clamping position for power and input for output cables cables Take particular note of the cable clamping arrangements –... -
Page 11: Cleaning
Connection types and ratings: LAN connection - RJ45 on Cat5 or Cat5e UTP cable • All other connections - 0.14mm² to 2.5mm² (26 to 14awg) for rigid/solid cables, • 0.14mm² to 1.5mm² (26 to 16awg) for flexible/stranded cable. Refer to safety information in section 5.2 Output 1 - rating 2A at 250Vac, 2A at 30Vdc Output 2 - 3A at 250Vac, 1A at 24Vdc (Note: for Output 1, a continuous current of 2A will cause a 22°... -
Page 12: Graffiti
Aftercare The purchase of your GAI-Tronics product does not end our commitment to you. In addition to our warranty obligations, GAI-Tronics are able to offer various levels of maintenance packages, installation and commissioning packages and technical support, from ad-hoc repairs to full maintenance contracts. -
Page 13: Repairs And Spare Parts
Repairs and Spare Parts. It is recommended that Help Points are returned to GAI-Tronics for service or repair, to ensure that any repairs are fully tested. In the event of work having to be carried out on site, the following spare parts are available:... -
Page 14: Technical Specifications
Technical Specifications Product features Power supply Nominal 48Vdc, 1A. (Voltage range: 36-56V) Ringer 80dBA @ 1m loudness Network 10/100 BaseT Ethernet RJ45, Cat5 or Cat5e UTP Static IP provisioning or DHCP Call Control SIP (RFC3261 compliant) Signalling Loose routing External 4 auxilliary inputs, volt free, (internal pull-up resistor source current = inputs 300uA) - Page 15 Environmental limits Temperature: Operating: -20° C to +60° C (-4° F to 140° F) Storing: -40° C to +70° C (-40° F to 158° F) Relative Up to 95% (non-condensing) Humidity Ingress IP65 to EN60529:1992 – Degrees of protection provided by enclosures. Protection Physical characteristics Casing...
- Page 16 Safety EN60950-1 – Specification for information technology equipment, including electrical business equipment. BS6317:1992 (Clause 13.9) - Specification for simple telephones for connection to public switched telephone networks run by certain public telecommunication operators. EN50371 - Generic standard to demonstrate the compliance of low power electronic and electrical apparatus with the basic restrictions related to human exposure to electromagnetic fields (10 MHz - 300 GHz).
-
Page 17: Ce Declaration
CE Declaration A copy of the current CE Declaration of Conformity is available from our website www.gai-tronics.org/support/certificates-approvals/ 400mm VoIP Help Point, 48V VoIP. -
Page 18: Licensing Notices
Licensing Notices The firmware in GAI-Tronics VoIP products contains modules subject to licensing and copyright as follows: Module License u-boot GPL V2 Linux kernel GPL V2 Busybox GPL V2 Opal/PWLib Mozilla Public License V1.1 Modutils GPL V2 GPL V2 David L. Mills Copyright Notice These licence and copyright notices are available in full from our website at www.gai-tronics.org/support/voip-support/... - Page 19 400mm VoIP Help Point, 48V VoIP.
- Page 20 Brunel Drive, Stretton Park Burton on Trent, DE13 0BZ England Tel: 01283 500500, Fax: 01283 500400 www.gai-tronics.co.uk The policy of GAI-Tronics is one of continuous improvement, therefore the Company reserves the right to change specifications without notice 400mm VoIP Help Point, 48V VoIP.
