Model 293-103, 297-103, 298-103,
293-103AL, and 294-103AL S.M.A.R.T.
Externally Powered Emergency Phones
Getting Started ................................................................................................................................1
Product Overview ................................................................................................................................... 1
Standard Operation ................................................................................................................................ 3
Placing an Emergency Call from a S.M.A.R.T. Phone (All Models) ...................................................................3
Placing a Non-Emergency Call (Models 294-103AL and 298-103 Only)............................................................3
Receiving a Call....................................................................................................................................................3
Disconnecting Calls ..............................................................................................................................................3
Installation ......................................................................................................................................4
Safety Guidelines..................................................................................................................................... 4
General Installation Guidelines ............................................................................................................. 4
Tamper-Resistant Hardware .................................................................................................................................4
Conduit Installation Details ..................................................................................................................................4
Models 293-103, 293-103AL, and 294-103AL....................................................................................... 5
Models 297-103 and 298-103 .................................................................................................................. 7
Setup ................................................................................................................................................9
Hardware Configuration........................................................................................................................ 9
Auto-answer Configuration ..................................................................................................................................9
Polarity Configuration ..........................................................................................................................................9
Audio Level Adjustment....................................................................................................................... 10
Auxiliary Output................................................................................................................................... 11
Programming......................................................................................................................................... 12
Enter the Programming Mode.............................................................................................................................12
Basic Programming Commands .........................................................................................................................13
Maintenance..................................................................................................................................15
Specifications ................................................................................................................................16
Confidentiality Notice ...................................................................................................................18
GAI-Tronics Corporation P.O. Box 1060, Reading, PA 19607-1060 USA
610-777-1374
V
ISIT WWW
G A I - T R O N I C S ® C O R P O R A T I O N
A H U B B E L L C O M P A N Y
T
C
A B L E O F
800-492-1212
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
O N T E N T S
Fax: 610-796-5954
Pub. 42004-377C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 293-103 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GAI-Tronics 293-103

  • Page 1: Table Of Contents

    Auxiliary Output........................... 11 Programming............................12 Enter the Programming Mode..........................12 Basic Programming Commands .........................13 Maintenance..........................15 Specifications ..........................16 Confidentiality Notice ........................18 GAI-Tronics Corporation P.O. Box 1060, Reading, PA 19607-1060 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
  • Page 2: Getting Started

    LED will light steadily. The LED remains lit until the call is disconnected. The GAI-Tronics S.M.A.R.T. Phone product line provides the flexibility to address a diverse range of applications. A wide variety of functions can be achieved by altering the configuration data stored in the phone’s non-volatile memory.
  • Page 3 PUB. 42004-377C 2 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES These functions are initially programmed during manufacturing and testing. After installation, they can be programmed remotely via DTMF data calls, either manually or through TMA. Set the emergency auto-dial phone numbers in accordance with your security plan.
  • Page 4: Standard Operation

    PUB. 42004-377C 3 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Standard Operation There are two types of telephones described in this manual. The first includes a single emergency push button and the second includes an emergency push button, a call push button, and telephone keypad. The operation of both is listed below.
  • Page 5: Installation

    • If an ac source is available within five feet of the telephone, the included power supply can be used. The ac source and power supply must be mounted in a dry location, such as a GAI-Tronics stanchion. • If the ac source is located more than five feet from the telephone, either extend the wiring of the included power supply, or provide a UL LISTED “Class 2”...
  • Page 6: Models 293-103, 293-103Al, And 294-103Al

    MERGENCY HONES Models 293-103, 293-103AL, and 294-103AL The mounting and wiring instructions for Models 293-103, 293-103AL and 294-103AL are as follows: 1. Remove the front panel of the telephone by removing the four tamper-resistant screws. 2. Remove the front panel of the enclosure.
  • Page 7 PUB. 42004-377C 6 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Figure 3. Model 293-103, 293-103AL, and 294-103AL Component Locations d:\standard ioms - current release\42004 instr. manuals\42004-377c.doc 08/06...
  • Page 8: Models 297-103 And 298-103

    Figure 4. Model 297-103 Figure 5. Model 298-103 1. When mounting in a GAI-Tronics Model 234 Series Stanchion or for flush-mount installations, the supplied back box must be used to mount the Model 297-103 or 298-103 Telephone. Mount the back box to the structure using the appropriate hardware.
  • Page 9 MERGENCY HONES For mounting the Model 297-103 and 298-103 S.M.A.R.T. Emergency Telephones in GAI-Tronics Model 236 Series Surface-Mount Enclosure and Model 234/234WM stanchions, please refer to the installation bulletin included with the enclosure or stanchion. The installation bulletins are also available at www.gai-tronics.com.
  • Page 10: Setup

    Disable: Insert the J14 jumper on pins 1 and 2 (Do not use this setting except under the direction of GAI-Tronics personnel.) : The Auto-answer feature must be enabled during remote programming, and to allow the GAI-Tronics Telephone Management Application PC to contact the phone. Polarity Configuration Factory Setting: Non-polarity sensitive This telephone can be configured to be polarity or non-polarity sensitive.
  • Page 11: Audio Level Adjustment

    PUB. 42004-377C 10 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Figure 7. Emergency Phone PCBA Audio Level Adjustment The speaker volume and microphone sensitivity are factory set to nominal levels that are acceptable for most installations. However, some installations may require adjustments for the speaker and microphone. Both the speaker and microphone adjustments are made using potentiometers on the emergency phone PCBA.
  • Page 12: Auxiliary Output

    MERGENCY duration of the emergency call. In many applications, the auxiliary output is used to operate a GAI-Tronics Model 530FB/531A Beacon (sold separately). For connection details, please refer to the Model 530FB/531A installation bulletin included with the beacon. Information is also available at www.gai-tronics.com.
  • Page 13: Programming

    PUB. 42004-377C 12 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Programming All S.M.A.R.T. Phone models are programmable. The phone settings are initially programmed during manufacturing and testing. Factory default settings can be found in Table R-1. The following section provides instructions for programming basic features needed to initially set up the phone from another touch-tone phone.
  • Page 14: Basic Programming Commands

    PUB. 42004-377C 13 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Basic Programming Commands The following programming commands can be entered from any touch-tone telephone. Acceptance of data transfer commands is indicated via a return code transmitted as an audible DTMF tone. Auto-dial Memory When the EMERGENCY button is pressed, the S.M.A.R.T.
  • Page 15 PUB. 42004-377C 14 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Call Timeout The call timeout feature is used to limit the maximum duration of a call. The call timeout can be any duration between one minute and 4 ½ hours. The duration is set in ½ second increments and the valid range is from 120 to 32,400.
  • Page 16: Maintenance

    PIN. The maintenance access PIN should be distributed only to trained maintenance personnel. If your S.M.A.R.T. Phone requires service, contact your GAI-Tronics Regional Service Center for a return authorization number (RA#). Equipment should be shipped prepaid to GAI-Tronics with a return authorization number and a purchase order number.
  • Page 17: Specifications

    Relative humidity.....................to 95%, no condensation PCBA (printed circuit board assembly) ................Conformal coated Model 293-103 Enclosure construction......Valox (high impact, glass-reinforced polyester) painted safety yellow Dimensions ............. 9.5 H × 8 W × 4 D inches (241.3 × 203.2 × 101.6 mm) Weight..............................
  • Page 18 PUB. 42004-377C 17 of 18 S.M.A.R.T. E ADA-C XTERNALLY OWERED OMPLIANT MERGENCY HONES Approvals Safety of Information Technology Equipment ..............UL/CSA 60950 Enclosures for Electrical Equipment..................UL 50, Type 3R 47 CFR Part 68 Certification Number ..................US: ADGTE03B294AL103X Ringer Equivalence Number....................AC-REN: 0.3B Network connection (USOC).......................
  • Page 19: Confidentiality Notice

    Tronics retains all intellectual property and other rights in or to the information contained herein, and such information may only be used in connection with the operation of your GAI-Tronics product or system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
  • Page 20 Buyer’s sole and exclusive remedy, and the warranty period on any repaired or replacement equipment shall be one (1) year from the date the original equipment was shipped. In no event shall GAI-Tronics warranty obligations with respect to equipment exceed 100% of the total cost of the equipment supplied hereunder.
