Summary of Contents for Vacon 100 Series
- Page 1 VACON 100 FAMILY ® AC DRIVES INSTALLATION IN US AND CANADA QUICK GUIDE...
-
Page 3: Table Of Contents
UL STANDARDS ON CABLING ................4 CABLE AND FUSE SIZES, NORTH AMERICA .............5 ....THE TECHNICAL DATA OF THE VACON® 100 FAMILY AC DRIVES THE CABLE AND FUSE SIZES FOR VACON® 100 FAMILY IN NORTH AMERICA, MAINS VOLTAGE 208-240 V AND 380-500 V ....8 THE CABLE AND FUSE SIZES FOR VACON®... -
Page 4: Ul Standards On Cabling
UL STANDARDS ON CABLING To obey the UL (Underwriters Laboratories) regulations, use a UL-approved Class 1 copper wire with a minimum heat resistance of +140 or +167 °F. You can use the drive on a circuit that gives a maximum of 100 000 rms symmetrical amperes, and a maximum of 600 V AC, when the drive is protected by Class T and J fuses. -
Page 5: Cable And Fuse Sizes, North America
National Electric Code and the local regulations. Do not use other devices than fuses to supply branch circuit protection. NOTE! The VACON 100 FLOW and HVAC software do not have the ® dynamic braking or the brake resistor functions. -
Page 6: The Technical Data Of The Vacon® 100 Family Ac Drives
THE TECHNICAL DATA OF THE VACON 100 FAMILY AC DRIVES ® Technical item or function Technical data 208-240V, 380-500V, 525-600V, Input voltage U in 525-690V,-10%…+10% * Input frequency 50-60 Hz, -5...+10% Connection to mains Once per minute or less Mains connection... - Page 7 NOTE! The UL approval is valid for input voltage up to 600 V. * = 525-600 V or 690 V are not available for VACON 100 HVAC. ® ** = For the motor thermal memory and the memory retention function to obey...
-
Page 8: The Cable And Fuse Sizes For Vacon® 100 Family
THE CABLE AND FUSE SIZES FOR VACON 100 FAMILY ® IN NORTH AMERICA, MAINS VOLTAGE 208-240 V AND 380-500 V... -
Page 10: The Cable And Fuse Sizes For Vacon® 100 Family
THE CABLE AND FUSE SIZES FOR VACON 100 FAMILY ® IN NORTH AMERICA, MAINS VOLTAGE 525-600 V... -
Page 12: The Tightening Torques Of Cable Terminals
THE TIGHTENING TORQUES OF CABLE TERMINALS... - Page 16 Download and read VACON 100 Family ® Installation manuals at: http://drives.danfoss.com/knowledge-center/technical-documentation/ DPD01758E...
