5 digit Loop-powered paneL meters
with Loop-powered BackLight
Loop Leader
•
4-20 mA Input
•
5 Digit LCD, 0.6" (15.2 mm) High
•
FM Type 4X, IP65 Front
•
Shallow Depth Case 3.2" Behind Panel
•
2 V Drop (5.7 V with Backlight)
•
Loop-Powered Backlight Standard
•
Custom Engineering Units & Bargraph
•
Linear, Square Root, or Programmable Exponent
•
Maximum & Minimum Display
•
Operating Temperature Range -30 to 65°C
•
Intrinsically Safe & Non-Incendive
•
HART Protocol Transparent
Precision Digital corPoration
+
TM
-
Series
model pd683 general purpose
model pd688 hazardous area
Model PD688 Only
www.predig.com
Advertisement
Related Manuals for PRECISION DIGITAL Loop Leader PD683
Summary of Contents for PRECISION DIGITAL Loop Leader PD683
- Page 1 Loop-Powered Backlight Standard • Custom Engineering Units & Bargraph • Linear, Square Root, or Programmable Exponent • Maximum & Minimum Display • Operating Temperature Range -30 to 65°C • Intrinsically Safe & Non-Incendive • HART Protocol Transparent www.predig.com Precision Digital corPoration...
-
Page 2: Key Features
modeL pd683 & pd688 Loop-powered paneL meters • Trend Arrow • 5 Digits, 0.6” High • Bargraph • Engineering Notation • Custom Engineering Units • Backlight is Standard keY FeatUres Square Root Function Through significant innovation in technology and design, we The square root extraction feature displays flow rate by extracting developed the Loop Leader™... -
Page 3: Main Menu
modeL pd683 & pd688 Loop-powered paneL meters setUp & programming PD688 Intrinsically Safe Wiring Easy Setup Installation must be performed in accordance with Control Drawing LIM688-2. Even with all the features packed into these meters, they’re still easy to setup and get running. Everything is programmed from the front Loop Input with Backlight panel buttons with no pots or jumpers to deal with. -
Page 4: Specifications
Model Description hereof, and specifically disclaims any implied warranties of merchantability or fitness for PDN-CAL 2-Point Calibration a particular purpose. ©2006 Precision Digital Corporation. all rights reserved PDN-CERTCAL Certificate of Calibration YoUr LocaL distriBUtor is: PDN-CERTCAL2 Certificate of Calibration with Data...
