- Page 1 Operator’s Super Star Gas Model 42-000-F and 42-001-E January 2015 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...
-
Page 2: Table Of Contents
CONTENTS Introduction ............ 1-15 Introduction ..................1 Symbols ..................2-3 Safety ....................4 Warning Decal Location ..............5 Safe Practices .................. 6 Super Star Specifications ..............7 Setup ....................8 Controls & Instruments Super Star 3WD ........... 9 Controls & Instruments Super Star 2WD .......... 10 Operation .................. -
Page 3: Introduction
All Smithco Smithco Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering Smithco Smithco parts. Refer to engine manual for placement of engine serial number. For product and accessory information, help finding a dealer, or to register your procuct please contact us at www.Smithco.com. -
Page 4: Symbols
Temperature Gasoline Diesel Glow Plug - On Glow Plug - Off Glow Plug Hour Meter Hour Meter Fuse Hand Throttle Choke - Closed Choke - Open Park Brake Hydraulic Oil Park Brake Release Level PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 5: Symbols
Up/Down Arrow Down/Lower Up/Raise Manual No Smoking Moving Parts Operation Step Hot Surface Pinch Point Hydraulic Fluid Lift Arm Tractor Penetration Engage Disengage Ground Speed Fast Slow Forward High Warning Danger Reverse Neutral Caution PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 6: Safety
It may also be used to alert against unsafe practices. CAUTION: Yellow. Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 7: Warning Decal Location
: When the rear rake attachment is lowered while the machine is in forward motion, the forward speed of the machine will slow drastically. Operator should be prepared for rapid change in speed. U.S. Patent # 5,725,068 25-337-P PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 8: Safe Practices
17. Keep the area of operation clear of all bystanders. 18. Never carry passengers. 19. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 20. Use parts and materials supplied by Smithco Smithco only. Do not modify any function or part. Smithco Smithco Smithco These machines are intended for professional maintenance on golf courses, sports turf, and any other area maintained turf and related trails, paths and lots. -
Page 9: Super Star Specifications
9" (23 cm) FLUID CAPACITY Crankcase Oil See Engine Manual Fuel 20 quarts (18.93 liters) Hydraulic Fluid 20 quarts (18.93 liters) Grade of Hydraulic Fluid SAE 10W-40 API Service SJ or higher Motor Oil PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 10: Setup
SETUP The Bunker Rakes arrive from Smithco Smithco with some assembly required before service. Smithco Smithco Smithco 1. Set park brake. Push the brake down past center and the park brake is engaged. 2. Rear wheel mounting. Block front tire. Jack up rear of machine being careful not to damage underside of machine. -
Page 11: Controls & Instruments Super Star 3Wd
(K) will give you a forward motion and pushing down on rear pedal (L) will give you a reverse motion. When pedal is released the hydrostatic transmission centers and stops the vehicle. Ground speed is proportional to how far the foot pedal is depressed. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 12: Controls & Instruments Super Star 2Wd
(L) will give you a reverse motion. When pedal is released the hydrostatic transmission centers and stops the vehicle. Ground speed is proportional to how far the foot pedal is depressed PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 13: Operation
Always stop the engine before reengaging the drive belt. The sudden application of power to the hydrostatic may cause serious damage the pump, the engine or both. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 14: Daily Checklist
Spring Loaded Locking Mecha- Adjustment Screws nism PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 15: Service Chart
SERVICE CHART Before servicing or making adjustments to the machine, stop engine, set park break, block wheels and remove key from ignition. Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine manual before maintenance. The suggested maintenance checklist is not offered as a replacement for the manufacturer’s engine manual but as a supplement. -
Page 16: Service Chart
END USER’S SERVICE CHART Duplicate this page for routine use. For the week of: Maintence Check Item Tues. Wed. Thurs. Fri. Sat. Sun. Check the Safety Seat Switch Check Steering Operation Check the fuel level Check the engine oil level. Clean the air filter Clean the engine cooling fins. -
Page 17: How To Rake A Sand Trap
HOW TO RAKE A SAND TRAP HOW TO RAKE A SAND TRAP View bunker to determine the most efficient pattern to follow so that rake pattern and configuration of bunker will flow in same general direction and look attractive. Enter bunker at its lowest point. Perhaps drain area or another point where “lip” of the trap is minimal. Operate at 2-4 m.p.h. -
Page 18: Service
4. Connect other end of cable (D) to engine block on unit being started (NOT to negative (-) terminal of battery) To prevent damage to other electrical components on unit being started, make certain that engine is at idle speed before disconnecting jumper cables. PARTS MANUALS AVAILABLE ONLINE AT smithco.com... -
Page 19: Other
Název stroje Maskinnavn Machinenaam Masina nimi Laitteen nimi Nom de la machine Maschinenbezeichnung Gépnév Denominazione della macchina Iek rtas nosaukums Mašinos pavadinimas Smithco Super Star Isem tal-Magna Nazwa urz dzenia Nome da Máquina Numele echipamentului Názov stroja Naziv stroja Nombre de la máquina Maskinens namn Designation Ozna ení... - Page 20 The place and date of the declaration Místo a datum prohlášení Sted og dato for erkl æringen Plaats en Smithco West Inc. datum van de verklaring Deklaratsiooni väljastamise koht ja kuupäev Vakuutuksen paikka ja päivämäärä Lieu et date de la déclaration 200 West Poplar Avenue Ort und Datum der Erklärung...
- Page 21 30 days from discovery of the condition. If you need help locating an Authorized Smithco Distributor, or if you have questions regarding your warranty rights or responsibilities, you may contact us at:...
- Page 22 This warranty does not apply to normal “wear and tear” items. Normal “Wear and Tear” includes, but is not lim- ited to, damage to seats due to wear or abrasion, worn painted surfaces, scratched decals or windows, etc. Smithco may require the return of failed parts or components in order to determine the validity of any warranty claim.
