Zaxcom ERX3TCD

ZaxNet Output Enable

ZAXNET OUTPUT
OFF
The ERX time code output can contain ZaxNet commands to communicate to other Zaxcom products. This
menu enables / disables the ERX to output the commands that are embedded within the time code output.
If the ERX is not sending the time code to another Zaxcom device this should be set to OFF.

Time Code Output Level Adjust

TC OUTPUT LEVEL:
1.0 VOLTS
The time code output level menu allows the time code voltage level to be adjusted to accommodate cameras
that need different time code voltage levels to lock time code.
The output level options are: .001, .003, .005, .010, .031, .062, .125, .250, .500, 1.000, 2.000, 3.000

Volume Knob Mode

VOLUME MODE:
VARIABLE
The volume knob mode menu will allow for the ERX volume control knob to be disabled.
This would be used to avoid an accidental change to the output level if an ERX is feeding audio to a camera.
Variable - Allows the volume knob function normally.
•
Fixed Max Gain - The volume knob will not function and the audio output will be set and locked to the level
•
that was set in the maximum volume menu.
Page 12
