IFB Receive Frequency Set

FREQ: 2.403 RX
SIGNAL: A01 B01
The IFB receive menu is where the ZaxNet receive frequency is set.
To manually adjust the receive frequency press the INC or DEC keys to match the transmit frequency.
When a valid signal is received, RX is displayed on the right side of the frequency. The second line displays the
signal strength and two vertical signal strength indicators will be displayed.
Pressing the TIME CODE key while on this page the ERX will cycle through the following:
FREQ - Overall signal strength of all antennas are displayed.
•
FRONT- Signal strength of only the front antennas are displayed.
•
SIDE - Signal strength of only the side antennas are displayed.
•
When using auto scan or when using the alternate frequency option the word "signal" on the bottom line of this
menu will show the actual frequency that the ERX is receiving on.

Audio Delay Set

AUDIO DELAY:
OFF
The audio delay menu sets a variable delay to the output audio. A delay is useful if the ERX is being used for
personal monitoring and there is a video processing delay to the monitors - so engaging the delay will delay the
audio to match the video. The audio delay can be adjusted from 5MS to 400MS in 5MS increments.

Software Update

PRESS UP 5X TO
UPDATE SOFTWARE
This menu is used to initiate the firmware update process.
After pressing the INC key 5 times, the ERX will start to look for firmware being transmitted from a compatible
transmitter. Please see the firmware section at the end of this manual for more information on how to update
the ERX.
