1. Connect the Monitor Power Adapter to the Monitor Unit.
2. Press and hold the
Monitor Unit. The POWER LED indicator will illuminate green to indicate the unit is ON.
3. Once both the Camera and Monitor Units are switched on, the display on the Monitor Unit
will show the video captured by the Camera Unit.
4. If there is no connection or you are out of range, the video display will go off and the screen
WARNING! Out of signal coverage
beep every 24 seconds. Move the Monitor Unit closer to the Camera Unit until the link is
re-established.
5. Press and hold the
scrolling, to turn OFF the Monitor Unit.
NOTE
The battery icon turns red on the LCD screen to indicate that the battery is low, and it
gives a beep periodically. The battery needs to be recharged. Fully charging the battery takes
about 7 hours.
When Charging
1. During power OFF, when adapter is plugged in, an adapter logo will display on screen and
the Charging LED Indicator will illuminate red to indicate charging, then turn blue to indicate
that the battery is fully charged.
2. During power ON, when adapter is plugged in, the
corner will show that the battery is charging. The Charging LED Indicator will also illuminate
red to indicate charging, then turn blue to indicate that the battery is fully charged.
NOTE
You can use the Monitor Unit while it is being charged.

3.5 Registration (Pairing)

The Camera Unit is pre-registered to your Monitor Unit. You do not need to register it again
unless the Camera Unit loses its link with the Monitor Unit. To re-register your Camera Unit, or
register a new Camera Unit, follow the procedure below:
1. Press the MENU button of the Monitor Unit and the menu bar will pop up.
2. Press the (icon) LEFT button or (icon) RIGHT button until
3. Press the (icon) UP button or (icon) DOWN button until (icon) icon is highlighted and press
the OK button.
POWER ON/OFF/SLEEP button for 2 seconds to turn ON the
will be shown on the LCD display. The unit will also
POWER ON/OFF/SLEEP button, until the progress bar finishes
battery icon on screen's top right
Cam icon is highlighted,
8
