4. Press the
UP button or
the OK button to start searching for a Camera Unit.
5. Press and hold the PAIR key on the right side of the Camera Unit for at least 3 seconds.
The Power LED light (green LED light, located directly below the camera lens aperture)
should flash green to indicate the Camera Unit is in pairing mode. If it does not flash,
press and hold the PAIR key until the LED light flashes.
6. If unsuccessful, delete the camera channel as per 5.6.1 on page 12 & 13, and attempt to
pair again.
NOTE
If a particular Camera Unit was previously registered with another Monitor Unit, registering
with the current Monitor Unit will overwrite the old registration on the Camera Unit.
9
DOWN button to select the desired CAM and press
