5. Locate the hole on the bottom of the Camera Unit and slide the hole over the screw sticking
out of the wall.
6. Check to see that the Camera Unit is secure. If it is loose, you may need to tighten the screw
more.
7. Use wall clips (not included) to secure the power cord away from the crib or baby's reach.

3.3 Monitor Unit Battery Installation

1. Insert the Rechargeable Li-ion Battery into the Battery Compartment as shown above.
2. Insert the wire tab of the Rechargeable Li-ion Battery into the contact slots as shown above.
3. Replace the battery cover over the compartment.

3.4 Charging and Powering the Monitor Unit

For best results, charge the Monitor Unit before use. After the initial charge, recharge
normally as required. The Monitor Unit can be operated normally with power adapter plugged
into the unit with the battery installed.
7
Red
Yellow
Black
