LOW-COST OEM PROCESS METER
Sabre Series
•
•
•
•
•
•
•
•
•
•
•
•
Precision Digital corPoration
0-20, 4-20 mA, 0-5, 1-5, 0-10, ±10 V Inputs
Input Current Overload Protection
NEMA 4X, IP65 Front
Shallow Depth 1/8 DIN Case 3.6" Behind Panel
4 Digit Display, 0.56" (14 mm) High, Red LEDs
Easy Front Panel Programming
Scale without a Signal Source
Calibrate with a Signal Source
Maximum/Minimum Display
Universal Power Supply 85-265 VAC
12-36 VDC/12-24 VAC Power Option
24 VDC @ 200 mA Transmitter Supply Option
•
Sabre P
Model PD603
www.predig.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sabre Series and is the answer not in the manual?

Questions and answers

Related Manuals for PRECISION DIGITAL Sabre Series

Summary of Contents for PRECISION DIGITAL Sabre Series

  • Page 1 LOW-COST OEM PROCESS METER Sabre Series • Sabre P Model PD603 • 0-20, 4-20 mA, 0-5, 1-5, 0-10, ±10 V Inputs • Input Current Overload Protection • NEMA 4X, IP65 Front • Shallow Depth 1/8 DIN Case 3.6” Behind Panel •...

  • Page 2: Front Panel Buttons

    • SABRE MODEL PD603 PROCESS METER EASy SETUP & PROgRAMMINg Setting Numeric Values The numeric values are set using the Right and Up arrow The Sabre P process meter is easily programmed using the buttons. Press the Right arrow button to select next digit four front panel buttons.
  • Page 3 • SABRE P MODEL PD603 PROCESS METER PROCESS INPUTS OPTIONAL FIELD ENCLOSURES The Sabre P meter is factory calibrated to accept 0-20, The Sabre P process meter is available with a wide variety of 4-20 mA, 0-5, 1-5, 0-10, and ±10 VDC. The meter can NEMA 4, NEMA 4X, and explosion-proof enclosures.

  • Page 4: Ordering Information

    Transmitter Supply: Isolated, P+, P-: 24 VDC ±10% @ 200 mA max Sabre Series Disclaimer The information contained in this document is subject to change without notice. Precision Digital LDS603_F 12/15 Corporation makes no representations or warranties with respect to the contents hereof, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose.
