30
47
Frost 1
Frost 0-100%
31
48
Frost 2
Frost 0-100%
32
49
Pan/tilt speed
Real-time motion
Delayed motion (rapid - slow)
33
50
Effects speed
Real-time effects
Delayed effects (rapid - slow)
34
51
Blackout Move
Not assigned
Blackout during pan/tilt
Blackout during Colour, CMY, Iris, Frost
Blackout during Colour, CMY, Iris, Frost, Zoom, Focus
Blackout during Colour, CMY, Iris, Frost, Pan/Tilt
Blackout during Colour, CMY, Iris, Frost, Zoom, Focus, Pan/Tilt
6.3 Control channel
Various spotlight functions can be permanently switched via the control channel. The response
behaviour via DMX, the cooling and volume, the repetition frequency of the LED module can
be switched and a spotlight reset can be triggered.
This channel can be used to adjust the response behaviour of the P18 Wash when dimming out
via faders to lighting controls from various manufacturers. Set DMX 000 for rapid dimming out
and DMX 007 for slow dimming out. This range is repeated five times and thus the P18 Wash
is adapted to the reaction time/speed of the light controllers (DMX 000-007 for "rapid" light
controllers and DMX 128-135 for "slow" light controllers).
In the range from DMX 160 to DMX 164 the "Cooling" and "Volume" operating modes can be set.
To do this, the dimmer and shutter of the spotlight must be closed and the corresponding DMX
value must then be transmitted for 2 seconds.
DMX 160 (62.8%): THEATRE WHISPER cooling mode
DMX 161 (63.2%): THEATRE SILENT cooling mode
DMX 162 (63.6%): STANDARD cooling mode
DMX 163 (64.0%): BOOST cooling mode
DMX 164 (64.4%): LONGLIFE cooling mode
The repetition frequency (50/60/600Hz/3kHz) of the LED engine can also be set via this channel.
DMX 208-215 Camera Mode, 50Hz (after 2 sec.)
DMX 216-223 Camera Mode, 60Hz (after 2 sec.)
DMX 224-231 Camera Mode, FLEX 600Hz (after 2 sec.)
DMX 224-231 Camera Mode, FLEX 3000Hz (after 2 sec.)
A spotlight reset can also be triggered.
DMX 240-247 Reset (after 2 sec.).
After the Cooling Mode, Camera Mode and Reset commands, this channel must be reset to its
original value. See channel assignment on page 22.
P1 8 Wash
000-255
000-255
000-003
004-255
000-003
004-255
000-095
096-127
128-159
160-191
192-223
224-255
- 25 -
