Electronics Line CommPact Quick Start Installation Manual page 7

Quick Option Name
Key
9>1>1>2 Zone Type
9>1>1>3 Set
1 (F): The zone is included in Full setting
2 (P): The zone is included in Part setting
3 (PE): The zone is included in Perimeter setting
9>1>1>4 Descriptor
9>1>1>5 Bell (Sounder)
9>1>1>6 Chime
9>1>1>7 Force Set
Table 3: Parameter set
4. If required scroll thorough the other menu parameters and modify settings.
Step 3: Test the detectors
1. Go to the main menu and press
2. Enter your engineer code (default code '1111').
3. Enter [7]>[07]>[2] (Service > Transmitters > TX Test) to initiate the TX
communication test. This test enables to identify transmitters and test their
signal strength.
4. Activate the transmitter to test; the transmitter's details appear on the
CommPact LCD and a sequence of tones is heard indicating the transmitter's
signal strength.
Signal Strength
0-2
3-5
6-8
8-9
Table 4: Signal strength
Description and Notes
The alarm this zone generates
Setting methods in which the zone is included.
Descriptors help identify the device when you operate
and program the system.
Activate the sounder when the zone is triggered
Activate the internal sounder when the zone is triggered.
Note: To allow the chime option enable Global Chime
option [Quick key 7>12]
Enables to set the system even if this zone is not ready.
For the force set feature to function, you must also enable
force setting in system options.
' '
√ .
Tones
1 Tone
2 Tones
3 Tones
4 Tones
7
Note:
If the signal strength is less
than 6, place the devices in
a better location.
