Note:
Account number 3 is designed for using Follow me feature. It is the only telephone
number that can be programmed by the user in the following location (only if defined as
SMS or TWA): Main menu > '[5] Follow Me Number'
4. Enter the Follow Me telephone number and press '√'
5. Select the protocol from the following options:
Two Way Audio Follow Me
SMS Follow Me
Voice Report
6. Define the communication interface for Follow me: PSTN or GSM.
7. Scroll thorough the other menu parameters and press '√' to confirm
Note:
Using the ELAS, the number of Follow me destinations by SMS or Email can be expanded.
3.7. Set Time & Date
The time and date are used to stamp events in the event log. Additionally the time is
displayed on the LCD.
1. Go to the main menu and press '√'.
2. Enter engineer code (default code '1111')
3. Select [7] > [01] (Service > Set Time/Date).
4. Select '[1] Set Time'. Enter the current time and press '√'
5. The display shows '[2] Set Date' option. Enter the current date and press '√'.
Note:
If the time is set in 12hr format, use the

3.8. Set/Edit Users

The CommPact supports up to 32 individual user codes. Each of these codes is four
digits long. The ability to perform an operation is defined by your user code's
authorization level. Each code is defined with its own authority level. Follow Table 8 to
view the authorization level assigned to each of the codes
Notes:
Codes 1-29 can be edited only by the Master code.
Codes 30, 32 can only be edited by the engineer. (Code 32 - Engineer code, Code 30 the
Central Station TWA Code)
key to toggle between AM and PM.
.
11
.
