3.4.1. Detectors

The CommPact supports 33 security zones. Only one detector can be registered to each
zone. Zones 1-32 are intended for wireless detectors by default. Zone 33 is an on-board
hardwire zone (can be configured as NO, NC or EOL).
Step 1: Register a detector
1. Go to the main menu and select [9]>[1]>[1] (Programming> Devices > Zones)
2. Using the arrow keys, select a specific zone and press
Registration mode.
3. Send two transmissions from the detector. A confirmation sound is heard after
each successful signal (chime sound). After two successful transmissions a
confirmation beep is heard.
Sending the transmissions can be done in several ways, as summarized in
Table 2.
Device
PIR Detectors
Magnetic Contact
Flood Sensor
Universal
Transmitter
Glass break
Smoke Detector
Table 2: Transmission sending
4. After the detector is successfully registered the display shows: 'Save?'
' '
Press √ to confirm and continue entering other parameters for the chosen
device (see section below) or press X to go back and enroll additional zones.
Step 2: Set detector's parameters
1. Go to the main menu and select [9]>[1]>[1] (Programming > Devices > Zones)
2. Using the arrow keys select a specific zone and press
3. Set the main parameters for each zone, according to Table 3
Device Model
Number
EL-2645
EL-2645PI
EL-2601
EL-2661
EL-2602
EL-2606
EL-2603
Sending Transmissions
Apply battery power. Place the mode
jumper over pins 2 and 3 (Radio Mode);
the LED flashes.
OR
Depress the tamper switch twice, in rapid
succession.
When you apply battery power and the
tamper switch is open, the device enters
test mode in which a transmission is sent
every few seconds. You can terminate the
test mode by closing the tamper switch.
Press the test button. Verify that the
transmission LED is lit momentarily. Wait
five seconds and press the test button
again.
6
' '
√ . The system initiates
' '
√ .
