Note
If the end user is to perform the self registration on-line then the following CPID and CP
Password steps are not required.
Program the CPID
1. Go to the main menu and press '√'.
2. Enter your engineer code.
3. Enter [9] > [5] > [7] > [3] (Programming > Communications > Internet > CPID).
4. Enter an ID using the alphanumeric keypad. The ID length is up-to 16
characters. The ID must begin with a letter.
5. Press '√'.
Program the Control Panel password
1. Go to the main menu and press '√'.
2. Enter engineer code.
3. Enter [9] > [5] > [7] > [4] (Programming > Communications > Internet > CP
Password).
4. Enter a password using the alphanumeric keypad. The password length is up
to 16 characters. The password must begin with a letter.
5. Press '√'.
If the Control Panel does not succeed to connect to the ELAS, an error message is
displayed. Table 9 indicates the optional error messages.
LCD display
MEDIA LOSS
GPRS MODULE
XML FAIL
Table 9: Optional error messages
Trouble Description
GPRS network fail
CP fails to communicate
with the XML Proxy
14
Action
Check the SIM card placement,
make sure it supports GPRS, and
check SIM PIN code.
Check APN definitions (Name
[95761], User name [95762] and
password [95763])
Check ELAS IP address (Quick
key [9571])
