UpperCycle GX Trainer
Owner's Manual
1005765-0001 REV AC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UpperCycle GX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Life Fitness UpperCycle GX

Summary of Contents for Life Fitness UpperCycle GX

  • Page 1 UpperCycle GX Trainer Owner's Manual 1005765-0001 REV AC...
  • Page 3 Latin America and Caribbean* Spain Hong Kong Life Fitness, Inc. Life Fitness IBERIA Life Fitness Asia Pacific LTD Columbia Centre III C/Frederic Mompou 5,1º1ª 32/F, Global Trade Square 9525 West Bryn Mawr Avenue 08960 Sant Just Desvern Barcelona 21 Wong Chuk Hang Road Rosemont, IL 60018 U.S.A.

  • Page 4: Table Of Contents

    Effects of State Laws....................15 Warranty Coverage.....................15 © Copyright 2019, Life Fitness, a division of Brunswick Corporation. All Rights Reserved. Columbia Center III - 9525 West Bryn Mawr Ave., Rosemont, IL 60018 847-288-3300 www.lifefitness.com 1005765-0001 AC 2019 Page 4 of 16...

  • Page 5: Safety Instructions

    Follow instructions provided in this manual for correct body position and basic usage. DO NOT use or permit use of any equipment that is damaged and/or has worn or broken parts. For all Life Fitness equipment use only replacement parts supplied by Life Fitness.
  • Page 6 Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so. DO NOT ATTEMPT TO USE OR REPAIR ANY ACCESSORY APPROVED FOR USE WITH THE LIFE FITNESS EQUIPMENT WHICH APPEARS TO BE DAMAGED OR WORN.

  • Page 7: Getting Started Specifications - Uppercycle Gx Trainer

    2. Getting Started Specifications - UpperCycle GX Trainer UpperCycle GX Trainer is not suitable for therapeutic purposes. Product Class Braking System Speed Independent Product Gross Weight 172.2 lb (78.12 kg) Max User Weight 330 lb (150 kg) Minimum Safe Operating Surface Area 75.8”...

  • Page 8: Tank Filling

    NOTE: Where water quality is known to be poor, Life Fitness recommends the use of distilled water. 3. Move the adjuster handle to level 10, and begin filling. Do not fill past the calibration mark indicated on the tank! NOTE: The siphon valve must be closed to allow siphoning action to occur.

  • Page 9: Operation

    3. Operation Bluetooth Auto-Adjust Console Each rower is equipped with advanced console technology enabling Bluetooth connectivity with any compatible smart device. The console is designed to integrate with rowing and fitness apps and assist with effective training progression by capturing and comparing data for the competitive individual. Key Features: Auto Start: Commence cranking to activate.

  • Page 10: Options

    Item Data Readouts / Description Buttons Auto Adjustment Level. Built in potentiometer automatically adjusts the monitor's LEVEL resistance level to the position of the Adjuster Knob on the fluid tank. Press UP button for work time adjustment, will add 15 seconds per press, and will WORK UP BUTTON add 30 seconds after 1 minute per press.

  • Page 11: Calibration Procedure

    Calibration Procedure 1. Press and hold the RESET and DOWN buttons for 5 seconds. Time display will show "_ _ _ _". Item Description Reset Button Rest Down Button Time Display 2. Turn handle to Level 1. Press Reset. Display will now show Level 2. Level 1 Calibration is complete.

  • Page 12: Changing Resistance Level

    Changing Resistance Level Changing resistance on your UpperCycle GX Trainer is simple. The level of resistance is determined by the level indicator located on the side of the tank. Level one indicates lightest resistance, level twenty represents heaviest resistance. The tank’s variable fluid resistance technology ensures an instant catch and constant resistance throughout the pedaling.

  • Page 13: Maintenance

    Do not use any water treatment other than the tablets supplied with this unit. For replacement tablets, contact Customer Service. Water treatment schedules for the UpperCycle GX Trainer will vary according to the fluid tanks exposure to sunlight, but expect 8-12 months near a bright, sunlit window and 2 years or more for a darker location. At the point of finding the water slightly cloudy, add a chlorine Tablet.

  • Page 14: Troubleshooting Console

    I want to drain the fluid tank on my on its side to facilitate draining process. If draining indoors, a container capable UpperCycle GX Trainer. of holding 8 litres of water will be required. It is likely your PK tank belt requires tightening.

  • Page 15: Warranty What Is Covered

    Who Pays Transportation and Insurance For Service If the Product or any covered part must be returned to a service facility for repairs, We, Life Fitness, will pay all transportation and insurance charges for the first year. You are responsible for transportation and insurance charge after the first year.
  • Page 16 Metal Frame - 5 Year Limited Warranty Life Fitness will repair or replace the metal Main Frame should it fail due to any defect in materials or workmanship within 5 years of the original purchase. Warranty does not apply to frame coating.
