Optical Interface Base Board Safety Test Points

In addition to the command and diagnostic test points, there are three ground
reference test points. These reference points are electrically identical, but their
locations facilitate oscilloscope or chart recorder test leads connections.
Table 10 - OIBBS Test Points
Test Point Signal Name
TP1 +5V
TP2 DIAG_0
TP3 CMD_0
TP4 DIAG_1
TP5 CMD_1
TP6 DIAG_2
TP7 CMD_2
TP8 DIAG_3
TP9 CMD_3
TP10 DIAG_4
TP11 CMD_4
TP12 DIAG_5
TP13 CMD_5
TP14 TFB_A
TP15 GND
TP16 DIAG_6
TP17 CMD_6
TP18 DIAG_7
TP19 CMD_7
TP20 DIAG_10
TP21 CMD_8
TP22 DIAG_9
TP23 CMD_9
TP24 DIAG_8
TP25 CMD_10
TP26 DIAG_11
TP27 CMD_11
TP28 TFB_B
TP29 GND
TP30 DIAG_12
TP31 CMD_12
TP32 DIAG_13
TP33 CMD_13
TP34 DIAG_14
TP35 CMD_14
Rockwell Automation Publication 7000-UM203C-EN-P - September 2018
Description
Positive 5V Power Supply
OIB2 A, RX1 Diagnostic Feedback
OIB2 A, TX1 Firing Command Signal
OIB2 A, RX2 Diagnostic Feedback
OIB2 A, TX2 Firing Command Signal
OIB2 A, RX3 Diagnostic Feedback
OIB2 A, TX3 Firing Command Signal
OIB2 A, RX4 Diagnostic Feedback
OIB2 A, TX4 Firing Command Signal
OIB2 A, RX5 Diagnostic Feedback
OIB2 A, TX5 Firing Command Signal
OIB2 A, RX6 Diagnostic Feedback
OIB2 A, TX6 Firing Command Signal
OIB2 A Temperature Feedback Signal
Ground Reference for TP1 – TP14
OIB2 B, RX1 Diagnostic Feedback
OIB2 B, TX1 Firing Command Signal
OIB2 B, RX2 Diagnostic Feedback
OIB2 B, TX2 Firing Command Signal
OIB2 B, RX5 Diagnostic Feedback
OIB2 B, TX3 Firing Command Signal
OIB2 B, RX4 Diagnostic Feedback
OIB2 B, TX4 Firing Command Signal
OIB2 B, RX3 Diagnostic Feedback
OIB2 B, TX5 Firing Command Signal
OIB2 B, RX6 Diagnostic Feedback
OIB2 B, TX6 Firing Command Signal
OIB2 B Temperature Feedback Signal
Ground Reference for TP16 – TP28
OIB2 C, RX1 Diagnostic Feedback
OIB2 C, TX1 Firing Command Signal
OIB2 C, RX2 Diagnostic Feedback
OIB2 C, TX2 Firing Command Signal
OIB2 C, RX3 Diagnostic Feedback
OIB2 C, TX3 Firing Command Signal
