Introduction

General Specifications
Environmental Specifications
Specifications
This appendix provides general specifications for the PowerFlex™ 7000 drive
Safe Torque Off Option module.
Table 1 - General Specifications
Attribute
Standards
Safety category
Safety inputs
Maximum allowable input resistance
Conductor type
(1)
Conductor size
Strip length
(1) Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
IMPORTANT The following are environmental specifications for the OIBBS and OIB2
boards only. For detailed drive environmental specifications, see the user
manual pertaining to your drive frame size (see
page
Table 2 - Environmental Specifications
Category
Storage Temperature (all const.):
Shock - Packaged for Shipment
Vibration - Packaged for Shipment
Sinusoidal Loose Load:
Random Secured:
Rockwell Automation Publication 7000-UM203C-EN-P - September 2018
Value
EN 60204-1, IEC 61508, EN 61800-3, EN 61800-5-1, EN 61800-5-2,
EN 62061, EN ISO 13489
Cat. 3 and PLe per ISO 13849-1;
SIL CL3 per IEC 61508 and EN 62061
2 N.C.
110 Ω
Multi-conductor cable
2
0.3...5.2 mm (22...10 AWG)
10 mm (0.39 in.)
6).
Specification
-40...+70 °C (-40...+158 °F)
381 mm (15 in.) drop height
20.0 mm (0.8 in.) peak to peak, 2...5.186 Hz;
1.1 g peak from 5.186...20 Hz
2
Frequency (Hz)PSD (g /Hz)
10.004
20.1008
50.0008
90.012
200.012
1000.00008
A
Appendix
