- Page 1 INSTRUCTION MANUAL Full HD 32-inch Double-screen Multi-format LCD Color Monitor MLW- 3226 C Model Ikegami Tsushinki Co., Ltd.
- Page 2 Thank you for choosing this Ikegami HD Monitor. Please read this Instruction manual carefully to keep your Ikegami products at peak performance for a longer service period. All Ikegami products are designed and manufactured with utmost care and craftsmanship to provide long life and high quality performance, if it is properly used and maintained as outlined in this manual.
- Page 3 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN SA 1965 SA 1966 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning ash with arrowhead inside a triangle is intended to warn the user that parts inside the product are dangerous and many cause electrical hazards.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS 1. General 1) Read all instructions provided. 2) Save these instructions for future use. 3) Follow all warnings and instructions marked on the monitor equipment. 4) Never insert objects of any kind into this monitor through cabinet slots as they may come in contact with dangerous voltage points or short out parts, resulting in re or electrical hazards, Never spill liquid of any kind on the monitor.
- Page 5 3) Upon completion of any service or repairs to this monitor, ask the service technician to perform routine safety checks to determine that the Color LCD Display is in safe operating condition. 4) For repair service, contact Ikegami’s authorized sales representative or Ikegami service desk directly. OPERATING PRECAUTIONS 1) Never let this unit fall or subject it to strong shock.
-
Page 6: Table Of Contents
Contents 1. Precautions ......................1 2. General Description ....................4 2.1 Features ......................4 2.2 About Input Signals ..................4 2.3 Functions ....................... 5 3. Names of Parts ...................... 6 3.1 Names of Parts and Their Functions ............6 4. Input Signal Connection ..................7 4.1 NTSC/PAL Analog Video . -
Page 7: Precautions
1. Precautions • When you open the cardboard box of the LCD monitor, please check that the indicated accessories and cables are present. It is recommended not to dispose of the packaging materials and to store them for later use if it becomes necessary to transport again for after-sales service, or maintenance purposes. - Page 8 1. Precautions Warning on power connection. The United States Canada Continental Europe NEMA 5-15P NEMA 5-15P CEE7 Plug Type HOSPITAL HOSPITAL EURO GRADE GRADE Rated Voltage & 10A/125V 10A/125V 10A/250V Current Safety Approval Plug Con guration Power Cord Type SJT Type SJT H05VV-F Use a proper power cord for your local power supply.
- Page 9 1. Precautions Maintenance • Clean the cabinet, panel and controls with a soft cloth lightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent, such as benzene. • Do not rub, touch, or tap the surface of the screen with sharp or abrasive items such as a ball-point pen or screwdriver.
-
Page 10: General Description
Meeting many safety standards The medical-use monitor conforms to US UL60601-1 and Canadian CSA22.2 No. 601.1 (cUL). MLW-3226C is a monitor intended for use in a medical environment to display pictures from cameras or other system. 2.2 About Input Signals... -
Page 11: Functions
2. General Description 2.3 Functions Color temperature switching function The color temperatures can be chosen from 6500K, 9300K and user settings to select a color rendering to your taste. Gamma level switching function The gamma level can be selected, compatible with DICOM14, from 1.8 to 2.6 (in 0.2 increments), Aspect ratio switching function The display aspect ratio of video signals can be switched to either the 4:3 or 16:9 view... -
Page 12: Names Of Parts
3. Names of Parts 3.1 Names of Parts and Their Functions Front Power indicator ○ Standby power switch ○ Input 1 ○ Input 2 ○ MENU ○ PIP SEL /- ○ SWAP/+ ○ Contrast/ ○ Brightness/Exit Back SDI1 input ○ SDI1 output ○... -
Page 13: Input Signal Connection
4. Input Signal Connection Connect the input signals in the following way. : Connected to the Video input. 4.1 NTSC/PAL Analog Video : Connected to the S-Video input. 4.2 NTSC/PAL Analog S-Video : Connected to PC input. (15P D-SUB connector) 4.3 RGB or YPbPr Analog signals : Connected to DVI input. -
Page 14: Operation
5. Operation 5.1 Key Operation There are seven front keys as shown below. −/PIP SEL Power Standby SW INPUT1 INPUT2 MENU +/SWAP CONT/BRT/EXIT Indicator The keys have the following functions. Standby SW : Used to turn on and off the power. INPUT1 : Switching of the input signal set to IN1 INPUT2... -
Page 15: Settings And Key Operation
5. Operation 5.2.3 Signal Name Display SD Video line : 480i, 575i HD Video line : 720P/50, 720P/60, 1080i/50, 1080i/60, 1080P/50, 1080P/60 (59.94 Hz is expressed as 60 Hz.) PC line : VGA, SVGA, XGA, SXGA, WUXGA, 480i, 575i, 720P/50, 720P/60, 1080i/50, 1080i/60, 1080P/50, 1080P/60 DVI line : VGA, SVGA, XGA, SXGA, WUXGA, 480i, 575i, 720P/50,... - Page 16 5. Operation 5.3.3 PIP SEL The double-screen display selector key is pressed to change the display in the order of PinP1, PinP2, SBS1, SBS2, SBS3 and SBS4. Switching operation is performed in the order stating from Single Screen → Multi- Preset No.
-
Page 17: Status Screen (Main, Sub)
User1 Color Mode User Gamma H/V.Frequency ＊＊.＊kHz / ＊＊.＊Hz Product Code MLW-3226C XXXXX ○ IN1: CH name - Signal name Switch behavior description IN2: CH name - Signal name Status setting screen description The selected input signal and the setting status are displayed. -
Page 18: User Setting Screen (Main, Sub)
5. Operation 5.5 User Setting Screen (Main, Sub) This screen is used to make the power save, backlight, OSD position and other settings. Screen display Status User Display Image Color Memory P-Pre DPMS OFF/ON BackLight 0-20 OSD Position OSD Time Out OFF/10s/30s/60s Signal Judge OFF/ON... -
Page 19: Display Setting Screen (Main)
5. Operation • Language : It is possible to switch the language used for displaying. • Reverse : This is a function for inverting the screen display: OFF : Normal display; ⇔ : Horizontal ip display; : Vertical ip display; : Vertical and horizontal ip display;... -
Page 20: Display Setting Screen (Sub)
5. Operation • H/V. Size : Used to adjust the horizontal and vertical sizes onscreen. Move toward the plus side to enlarge the display size. Move toward the minus side to reduce the display size. • Keep Aspect : It is possible to change screen size without changing aspect ratio in V.Size. -
Page 21: Image Setting Screen (Main, Sub)
5. Operation 5.8 Image Setting Screen (Main, Sub) This screen is used to adjust the contrast, brightness and other video signal-related display conditions. Screen display Status User Display Image Color Memory P-Pre Contrast 0 - 100 Brightness 0 - 100 Sharpness 0 - 22 Edg Freq... -
Page 22: Color Adjustment Screen (Main, Sub)
5. Operation • IP Mode : Used to select the interlaced-to-progressive conversion mode. Still : Nomal moving video mode. Motion : Low delay moving video mode. Still2 : Still image mode. Motion2 : Low delay still image mode. This mode can be selected for interlaced signals only. 5.9 Color Adjustment Screen (Main, Sub) This is a function for adjusting colors and for setting the signal formats. -
Page 23: Memory Select Screen (Main, Sub)
5. Operation 5.10 Memory Select Screen (Main, Sub) This screen is used to make the user memory settings and to return them to the factory ones. Display screen Status User Display Image Color Memory P-Pre User Memory User1/User2/User3/User4/User5/User6/User7/User8 User1 Input Control Video ○... - Page 24 5. Operation P-Pre select screen description • Preset No : Used to specify the Preset Number for double-screen setting. Four different types are available for setting. • Active : Speci es a Preset Number to be Active or Inactive. If it is set to OFF, the double-screen display of that Preset Number is deactivated.
- Page 25 5. Operation 5.12...
-
Page 26: Applicable Signals
6. Applicable Signals 6.1 Video Signals Input signal Name Video/S-Video DVI-D ※ 480i/60 ○ ○ ○ ○ ※ 575i/50 ○ ○ ○ ○ 480P/60 − − ○ − 575P/50 − − ○ − ※ 1080i/60 − ○ ○ ○ ※ 1080i/50 −... -
Page 27: Troubleshooting
7. Troubleshooting No image appears on the monitor screen. • Check to see if the AC power cord is tightly plugged in. • Check to see if the unit’s power switch is turned on. • Check the input signal. • Check to see if the input is selected as speci ed. •... - Page 28 7. Troubleshooting The screen size is wrong. • Check to see if the signal is listed in the applicable signals chart described under section 6. • On the Display Setting screen, set the AUTO. If the desired setting cannot be obtained, adjust H.Position, V.Position, H.Size, V.Size, and Clock.
- Page 29 (attached in Instruction Manual) Protection against electric shock Class I Degree of safety in the presence of Not suitable for use in the presence of ammable ammable anesthetics or oxygen anesthetics or oxygen. Mode of operation Continuous Manufacturers Ikegami Tsushinki Co., Ltd.
-
Page 30: Speci Cations
8. Specifi cations Appearance view <without stand type> 122.5 <with optional stand type> 122.5 Speci cations and design are subject to change for product improvements without notice. -
Page 31: Use The Stand
9. Use the stand • Clean work area. To protect monitor screen : wipe off work area and place monitor (Screen-side down) on a soft cloth or towel before proceeding with installation. top of monitor screen • Attach stand to monitor. Start screws as far as possible by hand, the tighten with screwdriver. - Page 32 146-8567 Phone:03 5700-1111 Fax:03 5700-1137 Ikegami Electronics (U.S.A.), Inc. 37 Brook Avenue, Maywood, New Jersey 07607 Phone:201 368-9171, Fax:201 569-1626 Ikegami Electronics (Europe) GmbH Ikegami Strasse 1, D-41460 Neuss, Germany Phone:02131 1230, Fax:02131 102820 Ikegami Electronics Phone: , Fax: Ikegami Tsushinki Co., Ltd.
