Page 1: Heat Exchanger
Installation and Operation Manual THERMAL STORES with stainless-steel DHW tube heat exchanger HSK 600 P, HSK 750 P, HSK 1000 P, HSK 1700 P HSK P 600-1700... -
Page 2: Table Of Contents
CONTENTS 1 Description ..............................1.1 Models ............................... 1.2 Tank protection ........................... 1.3 Thermal insulation ..........................1.4 Packaging ............................2 General Information ............................3 Technical Data and Dimensions of HSK P Model Line ................4 Operation ................................ 5 Typical Layout Examples with Thermal Store ..................... 6 Installation and Commissioning ........................ -
Page 3: Description
1 - Description HSK P Thermal Stores are intended for storing and subsequent distribution of thermal energy of heating water. They are fitted with a stainless-steel tube DHW heat exchanger, permitting installation of electric heating elements and connection of other heat sources. For a better thermal layering, the tank volume is separated by a baffle. For proper operation of a tank, it is necessary to have an optimum hydraulic design of the entire heating system, i.e. -
Page 4: Technical Data And Dimensions Of Hsk P Model Line
3 - Technical Data and Dimensions of HSK P Model Line Tank diameter with insulation HSK 600/1 P HSK 750/1 P HSK 1000/1 P HSK 1700/1 P Tank diameter pos. conn. height [mm] height G6/4"F 1010 1205 1240 G6/4"F G6/4"F 1570 1590 1635... -
Page 5: Operation
4 - Operation This tank is designed for heating and storing heating water in household or industrial applications, however always in closed pressure circuits with forced circulation. Hot water is heated inside the thermal store from several possible heat sources like various kinds of heating boilers, renewable energy sources or also electric heating elements. A stainless- -steel tube DHW heat exchanger is heated by heating water inside the thermal store. -
Page 6: Installation And Commissioning
6 - Installation and Commissioning Installation must meet valid rules and may be done only by qualified staff. Defects caused by improper installation, use or handling are not covered by warranty. After the tank is installed and connected to an existing heating system, it is recommended to clean the entire heating system using a suitable cleaning agent, e.g. - Page 7 4. Use the holes for tappings as a rest during the insulation installation. 5. At least one person presses the insulation to the tank, pulling both ends together. The other person closes the zipper. 6. Put on the upper insulation and cover 7.
-
Page 8: Maintenance
This product is covered by warranty under conditions specified in this Manual and the respective Warranty Certificate. The Warranty Certificate is an integral part of supply of this Thermal Store. v1.2-03/2019 ©2019 We reserve the right to errors, changes and improvements without prior notice. REGULUS spol. s r.o. E-mail: sales@regulus.eu Web: www.regulus.eu...
