LEDS
STS – STATUS LED
The Status LED is a dual color LED that provides information regarding the
state of the module. This includes indication of the various stages of the start-up
routine (power-up), as well as any errors that may occur.
Startup Routine
Module is currently running the boot loader and/or
Rapidly Flashing Red being flash upgraded by Crimson. This occurs for
four seconds during a power up.
Steady Red Module switching to configuration.
Green Module performing normally.

FIRMWARE UPGRADE

The module's firmware is stored in flash memory to prevent software/hardware
conflicts, and so that software features may be added in the future.
During a download, Crimson compares its own library of firmware files with
those stored in the Master module. If they do not match, Crimson will download
the necessary files. The Master then checks to make sure that the I/O modules
contain the same firmware. If they contain a different revision, the Master will
automatically copy those files into the module's flash memory. During this
process, the module LEDs will flash rapidly, starting with the top row, and
progressing through the remaining rows until the process is complete.

ORDERING INFORMATION

TYPE
Master Module
PID Control Modules
Communications Cables
(10 feet)
Software
Accessories
Note: Certain modules are not suitable for use in Hazardous locations. Check each module's specifications prior to installation.
1
Visit www.redlion.net for a complete list of PID modules, data acquisition modules, communications drivers and cables.
2
Free at www.redlion.net
MODEL NO.
Modular Controller Master, Multi Comms ports and Ethernet
Modular Controller Master with multiple protocol converter, Ethernet
and expansion slot
Modular Controller Master with multiple protocol converter, data
CSMSTR
logger, web server with Virtual HMI up to QVGA (320 x 240) size and
expansion slot.
Modular Controller Master with multiple protocol converter, data
logger, web server with Virtual HMI up to VGA (640 x 480) size and
expansion slot with increased SDRAM
Single Loop Module, Relay Outputs
Single Loop Module, Relay Outputs, Analog Output
Single Loop Module, Relay Outputs, Heater Current Input
1
CSPID1 Single Loop Module, Solid State Outputs
Single Loop Module, Solid State Outputs, Analog Output
Single Loop Module, Solid State Outputs, Heater Current Input
Single Loop Module, Triac Outputs, Analog Output
Dual Loop Module, Relay Outputs
Dual Loop Module, Relay Outputs, Heater Current Input
Dual Loop Module, Solid State Outputs
CSPID2
Dual Loop Module, Solid State Outputs, Heater Current Input
Dual Loop Module, Triac Outputs
Dual Loop Module, Triac Outputs, Heater Current Input
Programming Cable for CS, G3, & Paradigm Series
CBL
Communications Cables
®
Crimson Programming Software
®
Crimson Programming Software, Manual, and Download Cable
Rail Stops (Qty 2)
Replacement Base
Replacement Termination Plug
50 Amp Current Transformer (For Heater Current Models)
CT UL Recognized component, Instrument Transformers, Inc.
Part #2SFT500-0.1
Error States
Solid Red
Green/Pulsing Red
OP1, OP2, OP3, OP4* – OUTPUT STATUS LED
The OP1, OP2, OP3, and OP4* LEDs are factory configured to indicate the
status of the outputs. The LEDs turn on when the output is active.
These LEDs may be remapped to various other module properties.
*CSPID2 only
ALM OR AL1 & AL2 – ALARM LED
The Alarm LEDs are factory configured to indicate the presence of an alarm.
Whenever one of the seven alarms is active, the LED turns on.
These LEDs may be remapped to various other module properties.
CONFIGURATION
Programming is done via Crimson
configuration interface. Please see the Crimson manual for more information.
DESCRIPTION
1
2
7
Module not controlling, and not communicating.
Module is controlling properly, but has lost
communication with the Master.
®
software, a Windows
PART NUMBER
CSMSTRV2
CSMSTRLE
CSMSTRSX
CSMSTRGT
CSPID1R0
CSPID1RA
CSPID1RM
CSPID1S0
CSPID1SA
CSPID1SM
CSPID1TA
CSPID2R0
CSPID2RM
CSPID2S0
CSPID2SM
CSPID2T0
CSPID2TM
CBLPROG0
CBLxxxxx
SFCRM
SFCRK
RSRSTP00
CSBASE00
CSTERM00
CT005001
®
compatible
