5
Connect the Transceiver connection cable to the COM Port on Control
System Circuit Board
WARNING Switch OFF the main system power to the Load Center
before making any connections.
1.
Unlatch the enclosure door spring latche(s), and open the door.
2.
Remove the two retaining screws securing the high voltage cover-
panel, and remove it from the enclosure.
3.
Loosen the two access screws securing the control panel.
Access
screw
Control panel
Panel retaining
screw
(Cover-panel
not shown)
4.
Lower down the hinged control panel to access the circuit board.
SCREENLOGIC
INTERFACE Wireless Connection Kit Installation Guide
®
IntelliTouch
or EasyTouch
®
Load Center
®
Access
screw
Retaining
screw
