Step-by-step parameterisation

The DeltaTherm HC MAX is a controller that offers a broad variety of func-
®
tions to the user. At the same time, the user has a lot of freedom in configurating
them. Therefore, to set up a complex system, careful planning is required. We rec-
ommend drawing a sketch of the system first.
If planning, hydraulic construction and electrical connection have all been carried
out successfully, proceed as follows:
1. Running the commissioning menu
After the commissioning menu has been finished (see page 19), further adjust-
ments can be made. The commissioning menu can be repeated any time by means
of a reset (see page 59). Additional adjustments will be deleted.
For further information about the commissioning menu see page page 19.
2. Registering sensors
If flowmeters, flow switches, Grundfos Direct Sensors™, a FlowRotor, room con-
trol units, remote controls, switches and/or external extension modules are con-
nected, these have to be registered in the Inputs / Modules menu.
For further information about the registration of modules and sensors see page
62.
3. Adjusting heating circuits and activating optional heating functions
If one or more heating circuits are to be controlled, heating circuits can be activated
and adjusted.
For the heating part of the arrangement, up to 16 optional functions can be selected,
activated and adjusted.
To heating circuits and optional functions which require one or more relays, the
corresponding number of free relays can be allocated. The controller always sug-
gests the numerically smallest relay available.
Sensors can be allocated to more than one function.
For further information about heating circuits and optional heating functions see
page 36.
4. Activating optional arrangement functions
Up to 16 optional functions can be selected, activated and adjusted in the arrange-
ment part.
Relays available can be allocated to optional functions which require a relay. The
controller always suggests the numerically smallest relay available.
Sensors can be allocated to more than one function.
For further information about the optional arrangement functions see page 49.
