FILLING THE WATER TANK

If you want to use the evaporative cooling function, you need to add water to
the tank. Water can be filled from the top or the bottom:
1. From the top: First open the top loading reservoir, and then slowly pour
water into the tank (Fig. 3 & 4). Once full, return the cover to its original
position. Make sure to check the water level indicator in front of the unit
so as to not fill water beyond maximum level.
Open the top loading reservoir (Fig. 3)
3. Accessing the water tank (bottom): Before adding water to the water tank,
first slide the side lever to the top to raise the water pump to the top of
the tank:
Undo the latches on both sides (Fig. 5)
•
• Lift the top half of the unit and slowly pour water into the tank (Fig. 6).
After adding water:
• Place the top half of the unit back on top of the water tank
Fasten the side latches
•
• Slide the side lever down to move the tank to the bottom.
9
Fill water (Fig. 4)
