PARTS LIST
1. Top loading reservoir
2. Top cover
3. Left cover
4. Water pump side lever (raised)
5. Water pump side lever (lowered)
6. Water tank latch
7. Water tank
8. Casters
9. Remote control receiver
10. Horizontal louver
6
11. Front cover
12. Vertical louver
13. Back cover
14. Right cover
15. Power cord storage
16. Water gauge
17. Remote control
18. Dustproof filter
19. Cooling pad
20. Power cord
